YASKAWA A1000 Series User Manual

Drive Model
Normal Duty Heavy Duty
Rated Amps
(A)
<3>
Heatsink Loss
(W)
Interior Unit
Loss (W)
Total Loss (W)
Rated Amps
(A)
Heatsink Loss
(W)
Interior Unit
Loss (W)
Total Loss (W)
4A0088 88 684 308 993
75
<1>
563 254 817
4A0103 103 848 357 1205
91
<1>
723 299 1022
4A0139 139 1215 534 1749
112
<2>
908 416 1325
4A0165 165 1557 668 2224
150
<2>
1340 580 1920
4A0208 208 1800 607 2408
180
<2>
1771 541 2313
4A0250 250 2379 803 3182
216
<2>
2360 715 3075
4A0296 296 2448 905 3353
260
<2>
2391 787 3178
4A0362 362 3168 1130 4298
304
<2>
3075 985 4060
4A0414 414 3443 1295 4738
370
<2>
3578 1164 4742
4A0515 515 4850 1668 6518
450
<3>
3972 1386 5358
4A0675 675 4861 2037 6898
605
<3>
4191 1685 5875
4A0930 930 8476 2952 11428
810
<3>
6912 2455 9367
4A1200 1200 8572 3612 12184
1090
<3>
7626 3155 10781
<1> Value assumes the carrier frequency is set to 8 kHz or less.
<2>
Value assumes the carrier frequency is set to 5 kHz or less.
<3> Value assumes the carrier frequency is set to 2 kHz.
Table A.13 Watt Loss Three-Phase 600 V Class Three-Phase Models
Drive Model
Normal Duty Heavy Duty
Rated Amps
(A)
<3>
Heatsink Loss
(W)
Interior Unit
Loss (W)
Total Loss (W)
Rated Amps
(A)
Heatsink Loss
(W)
Interior Unit
Loss (W)
Total Loss (W)
5A0003 2.7 23.3 21.5 44.8
1.7
<2>
28.9 19.8 48.7
5A0004 3.9 33.6 27.5 61.1
3.5
<2>
54.3 27.6 81.9
5A0006 6.1 43.7 28.1 71.8
4.1
<2>
53.0 27.0 80.0
5A0009 9.0 68.9 43.4 112.3
6.3
<2>
78.7 36.4 115.1
5A0011 11 88.0 56.1 144.0
9.8
<2>
110.9 49.5 160.3
5A0017 17 146.7 96.6 243.2
12.5
<2>
144.7 67.5 212.2
5A0022 22 178.3 99.4 277.7
17
<2>
203.8 81.1 284.8
5A0027 27 227.2 132.1 359.3
22
<1>
267.2 113.8 381.1
5A0032 32 279.9 141.6 421.5
27
<1>
332.9 132.2 465.1
5A0041 41 330.8 136.2 467.0
32
<1>
405.9 127.6 533.5
5A0052 52 427.8 166.2 594.0
41
<1>
527.2 161.4 688.5
5A0062 62 791.2 279.0 1070.2
52
<1>
1271.5 335.0 1606.5
5A0077 77 959.1 329.4 1288.6
62
<1>
1457.0 379.5 1836.5
5A0099 99 1253.2 411.7 1664.9
77
<2>
1267.0 352.0 1619.0
5A0125 125 1641 537 2178
99
<3>
1328 422 1750
5A0145 145 1860 603 2463
130
<3>
1638 508 2146
5A0192 192 2420 769 3189
172
<3>
2114 648 2762
5A0242 242 3100 1131 4231
200
<3>
2526 896 3422
<1> Value assumes the carrier frequency is set to 8 kHz or less.
<2>
Value assumes the carrier frequency is set to 5 kHz or less.
<3> Value assumes the carrier frequency is set to 2 kHz.
A.4 Drive Watt Loss Data
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
247
A
Specifications

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
