H1 Multi-Function Digital Input Selections
H1-oo Setting
Function LCD Display Description Page
62
External Speed Search
command 2
Speed Search 2
Closed: Activates Current Detection Speed Search from the frequency
reference.
–
63 Field weakening Field Weak
Closed: The drive performs Field Weakening control as set for d6-01 and
d6-02.
–
65
KEB Ride-Thru 1
(N.C.)
KEB Ridethru NC Open: KEB Ride-Thru 1 enabled. –
66
KEB Ride-Thru 1
(N.O.)
KEB Ridethru NO Closed: KEB Ride-Thru 1 enabled. –
67
Communications test
mode
Comm Test Mode
Tests the MEMOBUS/Modbus RS-422/RS-485 interface. Displays
“PASS” if the test completes successfully.
–
68
High Slip Braking
(HSB)
HighSlipBraking
Closed: Activates High Slip Braking to stop the drive during a Run
command.
–
6A Drive enable Drive Enable
Open: Drive disabled. If this input is opened during run, the drive will stop
as specified by b1-03.
Closed: Ready for operation.
–
71
Speed/Torque control
Sswitch
Spd/Trq Ctl Chng
Open: Speed Control
Closed: Torque Control
–
72 Zero servo Zero Servo Cmd Closed: Zero Servo enabled –
75 Up 2 command Up Command 2
Used to control the bias added to the frequency reference by the Up/Down
2 function. The Up 2 and Down 2 commands must always be used in
conjunction with one another.
–
76 Down 2 command Down Command 2
Used to control the bias added to the frequency reference by the Up/Down
2 function. The Up 2 and Down 2 commands must always be used in
conjunction with one another.
–
77 ASR gain switch ASR Gain Switch
Open: ASR proportional gain 1 (C5-01)
Closed: ASR proportional gain 2 (C5-03)
–
78
External torque
reference polarity
inversion
Tref Sign Change
Open: Forward torque reference.
Closed: Reverse polarity.
–
7A
KEB Ride-Thru 2
(N.C.)
KEB Ridethru2NC
Open: KEB Ride-Thru 2 enabled. Drive disregards L2-29 and performs
Single Drive KEB Ride-Thru 2.
–
7B
KEB Ride-Thru 2
(N.O.)
KEB Ridethru2NO
Closed: KEB Ride-Thru 2 enabled. Drive disregards L2-29 and performs
Single Drive KEB Ride-Thru 2.
–
7C
Short circuit braking
(N.O.)
SC Brake (NO) Closed: Short Circuit Braking enabled –
7D
Short circuit braking
(N.C.)
SC Brake (NC) Open: Short Circuit Braking enabled –
7E
Forward/reverse
detection
PG Rotate Rev
Open: Forward motor operation detected
Closed: Reverse motor operation detected
–
7F
PID Bi-Directional
Enable
PID BiDir Enable Reserved. –
90 to 97
DriveWorksEZ
digital inputs 1 to 8
– Reserved for DWEZ input functions –
9F DriveWorksEZ disable DWEZ Disable
Open: DWEZ enabled
Closed: DWEZ disabled
–
u
H2: Multi-Function Digital Outputs
No.
(Addr.
Hex)
Name LCD Display Description Values Page
H2-01
(040B)
Terminal M1-M2
function selection
(relay)
M1-M2 Func Sel
Refer to H2 Multi-Function Digital Output Settings on pages
292 to 294 for descriptions of setting values.
Default: 0
Range: 0 to 192
153
H2-02
(040C)
Terminal M3-M4
function selection
(relay)
M3/M4 Func Sel
Default: 1
Range: 0 to 192
153
H2-03
(040D)
Terminal M5-M6
function selection
(relay)
M5/M6 Func Sel
Default: 2
Range: 0 to 192
153
B.7 H Parameters: Multi-Function Terminals
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
291
B
Parameter List
