Three-Phase 200 V Class Drive Models 2A0040 to 2A0211
Table A.3 Power Ratings Continued (Three-Phase 200 V Class)
Item Specification
Drive Model 2A0040 2A0056 2A0069 2A0081 2A0110 2A0138 2A0169 2A0211
Maximum Applicable Motor Capacity
(HP)
<1>
ND Rating 15 20 25 30 40 50 60 75
HD Rating 10 15 20 25 30 40 50 60
Input
Input Current (A)
<2>
ND Rating 52 68 80 92 111 136 164 200
HD Rating 37 52 68 80 82 111 136 164
Rated Voltage
Rated Frequency
Three-phase 200 to 240 Vac 50/60 Hz/270 to 340 Vdc
<3>
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency Fluctuation ±5%
Input Power (kVA)
ND Rating 24 31 37 42 51 62 75 91
HD Rating 17 24 31 37 37 51 62 75
Output
Rated Output Capacity
(kVA)
<4>
ND Rating
<5>
15.2 21 26 31 42 53 64 80
HD Rating
12.6
<6>
17.9
<6>
23
<6>
29
<6>
32
<6>
44
<6>
55
<7>
69
<7>
Rated Output Current (A)
ND Rating
<5>
40 56 69 81 110 138 169 211
HD Rating
33
<6>
47
<6>
60
<6>
75
<6>
85
<6>
115
<6>
145
<7>
180
<7>
Overload Tolerance
ND Rating: 120% of rated output current for 60 s
HD Rating: 150% of rated output current for 60 s
(Derating may be required for applications that start and stop frequently)
Carrier Frequency User adjustable between 1 and 15 kHz
User adjustable
between 1 and
10 kHz
Maximum Output Voltage (V) Three-phase 200 to 240 Vac (proportional to input voltage)
Maximum Output Frequency (Hz) 400 Hz (user-set)
<1> The motor capacity (HP) refers to a NEC rated 4-pole motor. The rated output current of the drive output amps should be equal to or greater than
the motor current. Select the appropriate capacity drive if operating the motor continuously above motor nameplate current.
<2>
Assumes operation at the rated output current. Input current rating varies depending on the power supply transformer, input reactor, wiring
connections, and power supply impedance.
<3> DC input is not available for UL standards.
<4> Rated motor capacity is calculated with a rated output voltage of 220 V.
<5> Carrier frequency is set to 2 kHz. Current derating is required in order to raise the carrier frequency.
<6> Carrier frequency can be increased to 8 kHz while keeping this current derating. Higher carrier frequency settings require derating.
<7> Carrier frequency can be increased to 5 kHz while keeping this current derating. Higher carrier frequency settings require derating.
A.2 Power Ratings
236
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
