YASKAWA A1000 Series User Manual

u
Three-Phase 200 V Class Drive Models 2A0250 to 2A0415
Table A.4 Power Ratings Continued (Three-Phase 200 V Class)
Item Specification
Drive Models 2A0250 2A0312 2A0360 2A0415
Maximum Applicable Motor Capacity (HP)
<1>
ND Rating 100 125 150 175
HD Rating 75 100 125 150
Input
Input Current (A)
<2>
ND Rating 271 324 394 394
HD Rating 200 271 324 394
Rated Voltage
Rated Frequency
Three-phase 200 to 240 Vac 50/60 Hz/270 to 340 Vdc
<3>
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency Fluctuation ±5%
Input Power (kVA)
ND Rating 124 148 180 215
HD Rating 91 124 148 180
Output
Rated Output Capacity (kVA)
<4>
ND Rating
<5>
95 119 137 158
HD Rating
82
<6>
108
<6>
132
<6>
158
<5>
Rated Output Current (A)
ND Rating
<5>
250 312 360 415
HD Rating
215
<6>
283
<6>
346
<6>
415
<5>
Overload Tolerance
ND Rating: 120% of rated output current for 60 s
HD Rating: 150% of rated output current for 60 s
(Derating
may be required for applications that start and stop frequently)
Carrier Frequency User adjustable between 1 and 10 kHz
Maximum Output Voltage (V) Three-phase 200 to 240 Vac (proportional to input voltage)
Maximum Output Frequency (Hz) 400 Hz (user-set)
<1> The motor capacity (HP) refers to a NEC rated 4-pole motor. The rated output current of the drive output amps should be equal to or greater than
the motor current. Select the appropriate capacity drive if operating the motor continuously above motor nameplate current.
<2>
Assumes operation at the rated output current. Input current rating varies depending on the power supply transformer, input reactor, wiring
connections, and power supply impedance.
<3> DC input is not available for UL standards.
<4> Rated motor capacity is calculated with a rated output voltage of 220 V.
<5> Carrier frequency is set to 2 kHz. Current derating is required in order to raise the carrier frequency.
<6> Carrier frequency can be increased to 5 kHz while keeping this current derating. Higher carrier frequency settings require derating.
A.2 Power Ratings
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
237
A
Specifications

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
