YASKAWA A1000 Series User Manual

u
Three-Phase 400 V Class Drive Models 4A0208 to 4A1200
Table A.7 Power Ratings Continued (Three-Phase 400 V Class)
Item Specification
Drive Models 4A0208 4A0250 4A0296 4A0362 4A0414 4A0515 4A0675 4A0930 4A1200
Maximum Applicable Motor
Capacity (HP)
<1>
ND Rating 150 200 250 300 350 400-450 500-550 750 1000
HD Rating 125-150 150 200 250 300 350
400-450-
500
650 900
Input
Input Current (A)
<2>
ND Rating 207 248 300 346 410 465 657 922 1158
HD Rating 170 207 248 300 346 410 584 830 1031
Rated Voltage
Rated Frequency
Three-phase: 380 to 480 Vac 50/60 Hz/510 to 680 Vdc
<3>
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency Fluctuation ±5%
Input Power (kVA)
ND Rating 189 227 274 316 375 425 601 843 1059
HD Rating 155 189 227 274 316 375 534 759 943
Output
Rated Output Capacity
(kVA)
<4>
ND Rating
<5>
189 227 274 316 375 425 601 843 1059
HD Rating
137
<6>
165
<6>
198
<6>
232
<6>
282
<6>
343
<5>
461
<5>
617
<5>
831
<5>
Rated Output Current
(A)
ND Rating
<5>
208 250 296 362 414 515 675 930 1200
HD Rating
180
<6>
216
<6>
260
<6>
304
<6>
370
<7>
450
<5>
605
<5>
810
<5>
1090
<5>
Overload Tolerance
ND Rating: 120% of rated output current for 60 s
HD Rating: 150% of rated output current for 60 s
(Derating may be required for applications that start and stop frequently)
Carrier Frequency User-adjustable between 1 and 10 kHz User-adjustable between 1 and 5 kHz
Maximum Output Voltage (V) Three-phase: 380 to 480 Vac (proportional to input voltage)
0.95 ×
[input voltage]
Maximum Output Frequency (Hz) 400 Hz (user-adjustable)
<1> The motor capacity (HP) refers to a NEC rated 4-pole motor. The rated output current of the drive output amps should be equal to or greater than
the motor current. Select the appropriate capacity drive if operating the motor continuously above motor nameplate current.
<2> Assumes
operation at the rated output current. Input current rating varies depending on the power supply transformer, input reactor, wiring conditions,
and power supply impedance.
<3> DC input is not available for UL standards.
<4> Rated motor capacity is calculated with a rated output voltage of 440 V.
<5> Carrier frequency is set to 2 kHz. Current derating is required in order to raise the carrier frequency.
<6> Carrier frequency can be increased to 5 kHz while keeping this current derating. Higher carrier frequency settings require derating.
<7> Carrier frequency can be increased to 5 kHz while keeping this current derating. Higher carrier frequency settings require derating.
A.2 Power Ratings
240
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
