u
d3: Jump Frequency
No.
(Addr.
Hex)
Name LCD Display Description Values Page
d3-01
(0294)
Jump Frequency 1 Jump Freq 1
Eliminates problems with resonant vibration of the motor/
machine by avoiding continuous operation in predefined
frequency ranges. The drive accelerates and decelerates the
motor through the prohibited frequency ranges.
Setting 0.0 disables this function.
Parameters must be set so that d3-01
≥ d3-02 ≥ d3-03.
Default:
<1> <2>
Min.: 0.0
<2>
Max.: 400.0
<2>
d3-02
(0295)
Jump Frequency 2 Jump Freq 2
Eliminates problems with resonant vibration of the motor/
machine by avoiding continuous operation in predefined
frequency ranges. The drive accelerates and decelerates the
motor through the prohibited frequency ranges.
Setting 0.0 disables this function.
Parameters must be set so that d3-01
≥ d3-02 ≥ d3-03.
Default:
<1> <2>
Min.: 0.0
<2>
Max.: 400.0
<2>
d3-03
(0296)
Jump Frequency 3 Jump Freq 3
Eliminates problems with resonant vibration of the motor/
machine by avoiding continuous operation in predefined
frequency ranges. The drive accelerates and decelerates the
motor through the prohibited frequency ranges.
Setting 0.0 disables this function.
Parameters must be set so that d3-01
≥ d3-02 ≥ d3-03.
Default:
<1> <2>
Min.: 0.0
<2>
Max.: 400.0
<2>
d3-04
(0297)
Jump Frequency Width Jump Bandwidth
Sets the dead-band width around each selected prohibited
frequency reference point.
Default:
<1> <3>
Min.: 0.0
<3>
Max.: 20.0
<3>
<1> Default setting is determined by parameter A1-02, Control Mode Setting.
<2>
Default setting is 0.0% and setting range is 0.0 to 100.0% in AOLV/PM or CLV/PM.
<3> Default setting is 1.0% and setting range is 0.0 to 40.0% in AOLV/PM and CLV/PM.
u
d4: Frequency Reference Hold and Up/Down 2 Function
No.
(Addr.
Hex)
Name LCD Display Description Values Page
d4-01
(0298)
Frequency Reference
Hold Function Selection
Fref Hold Sel
0: Disabled
1: Enabled
0: Disabled. Drive starts from zero when the power is switched
on.
1:
Enabled. At power up, the drive starts the motor at the Hold
frequency that was saved.
Default: 0
Range: 0, 1
d4-03
(02AA)
Frequency Reference
Bias Step (Up/Down 2)
Up/Dn 2 Step Lvl
Sets the bias added to the frequency reference when the Up 2
and Down 2 digital inputs are enabled (H1-oo = 75, 76).
Default: 0.00 Hz
Min.: 0.00
Max.: 99.99
d4-04
(02AB)
Frequency Reference
Bias Accel/Decel (Up/
Down 2)
Up/Dn 2 Ramp Sel
0: Sel Acc/Dec Time
1: Acc/Dec Time 4
0: Use selected accel/decel time.
1: Use accel/decel time 4 (C1-07 and C1-08).
Default: 0
Range: 0, 1
d4-05
(02AC)
Frequency Reference
Bias Operation Mode
Selection (Up/Down 2)
Up/Dn 2 Bias Sel
0: Hold Bias Value
1: Reset Bias Value
0: Bias value is held if no input Up 2 or Down 2 is active.
1:
When the Up 2 reference and Down 2 reference are both on
or both off, the applied bias becomes 0. The specified accel/
decel times are used for acceleration or deceleration.
Default: 0
Range: 0, 1
d4-06
(02AD)
Frequency Reference
Bias (Up/Down 2)
Up/Dn 2 Bias Lvl
The Up/Down 2 bias value is saved in d4-06 when the
frequency reference is not input by the digital operator. Set as
a percentage of the maximum output frequency.
Default: 0.0%
Min.: -99.9
Max.: 100.0
d4-07
(02AE)
Analog Frequency
Reference Fluctuation
Limit (Up/Down 2)
Up/Dn 2 FluctLim
Limits how much the frequency reference is allowed to change
while an input terminal set for Up 2 or Down 2 is enabled. If
the frequency reference changes for more than the set value,
then the bias value is held and the drive accelerates or
decelerates to the frequency reference. Set as a percentage of
the maximum output frequency.
Default: 1.0%
Min.: 0.1
Max.: 100.0
d4-08
(02AF)
Frequency Reference
Bias Upper Limit (Up/
Down 2)
Up/Dn 2 UpperLim
Sets the upper limit for the bias and the value that can be saved
in
d4-06. Set as a percentage of the maximum output frequency.
Default: 100.0%
Min.: 0.0
Max.: 100.0
d4-09
(02B0)
Frequency Reference
Bias Lower Limit (Up/
Down 2)
Up/Dn 2 LowerLim
Sets the lower limit for the bias and the value that can be saved
in d4-06. Set as a percentage of the maximum output frequency.
Default: 0.0%
Min.: -99.9
Max.: 0.0
B.4 d: References
268
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
