YASKAWA A1000 Series User Manual

Item Specification
Protection
Functions
Motor Protection Electronic thermal overload relay
Momentary Overcurrent
Protection
Drive stops when output current exceeds 200% of Heavy Duty Rating
Overload Protection
Drive stops after 60 s at 150% of rated Heavy Duty output current
<9>
Overvoltage Protection
200 V class: Stops when DC bus voltage exceeds approx. 410 V
400 V class: Stops when DC bus voltage exceeds approx. 820 V
600 V class: Stops when DC bus voltage exceeds approx. 1040 V
Undervoltage Protection
200 V class: Stops when DC bus voltage falls below approx. 190 V
400 V class: Stops when DC bus voltage falls below approx. 380 V
600 V class: Stops when DC bus voltage falls below approx. 475 V
Momentary Power Loss
Ride-Thru
Immediately stop after 15 ms or longer power loss.
<10>
Continuous operation during power loss than 2 s (standard)
<11>
Heatsink Overheat
Protection
Thermistor
Braking Resistor Overheat
Protection
Overheat input signal for braking resistor (Optional ERF-type, 3% ED)
Stall Prevention Stall Prevention is available during acceleration, deceleration, and during run.
Ground Protection
Electronic circuit protection
<12>
DC Bus Charge LED Remains lit until DC bus voltage falls below 50 V
Environment
Area of Use Indoors
Ambient Temperature
IP20/NEMA 1, UL Type 1 enclosure: -10 °C to +40 °C (14 °F to 104 °F)
IP00 enclosure: -10 °C to +50 °C (14 °F to 122 °F)
Finless Type: IP20/IP00 enclosure: -10 °C to +45 °C (14 °F to 113 °F)
Humidity 95 RH% or less (no condensation)
Storage Temperature -20 °C to +60 °C (-4 °F to +140 °F) short-term temperature during transportation
Altitude Up to 1000 meters without derating, up to 3000 m with output current and voltage derating.
Vibration/Shock
10 to 20 Hz: 9.8 m/s
2 <13>
20 to 55 Hz: 5.9 m/s
2
(2A0004 to 2A0211, 4A0002 to 4A0165, and 5A0003 to 5A0099)
2.0 m/s
2
(2A0250 to 2A0415, 4A0208 to 4A1200, and 5A0125 to 5A0242)
Standard
• UL508C
•
IEC/EN 61800-3, IEC/EN 61800-5-1
• Two Safe Disable inputs and one EDM output according to ISO/EN 13849-1 Cat. 3 PLd, IEC/EN
61508 SIL2
• CSA
Protection Design
IP00/Open Type enclosure, IP20/NEMA 1, UL Type 1 enclosure
<14>
<1> Select control modes in accordance with drive capacity.
<2> High-frequency current superposition (n8-57=1) is available.
<3> Perform Rotational Auto Tuning.
<4> Contact Yaskawa or your nearest sales representative if using a PM motor other than Super Energy-saving Motors manufactured by Yaskawa Motor
Co., Ltd. (SSR1 series and SST4 series with standard specifications).
<5> The accuracy of these values depends on motor characteristics, ambient conditions, and drive settings. Specifications may vary with different motors
and with changing motor temperature. Contact Yaskawa for consultation.
<6> Disable Stall Prevention during deceleration (L3-04 = 0) when using a regenerative converter, a regenerative unit, a braking resistor or the Braking
Resistor Unit. The default setting for the Stall Prevention function will interfere with the braking resistor.
<7> Instantaneous average deceleration torque refers to the torque required to decelerate the motor (uncoupled from the load) from the rated motor speed
down to zero in the shortest time.
<8> Actual specifications may vary depending on motor characteristics.
<9> Overload protection may be triggered when operating with 150% of the rated output current if the output frequency is less than 6 Hz.
<10> May be shorter due to load conditions and motor speed.
<11> A separate Momentary Power Loss Ride-Thru Unit is required for models 2A0004 to 2A0056 and 4A0002 to 4A0031 if the application needs to
continue running for up to 2 seconds during a momentary power loss.
<12> Ground protection is triggered when a ground short circuit occurs while the drive is running. The ground protection cannot be provided when the
impedance of the ground fault path is too low, or when the drive is powered up while a ground fault is present at the output.
<13>
Models 4A0930 and 4A1200 are rated at 5.9 m/s
2
.
<14> Removing the top protective cover or bottom conduit bracket from an IP20/NEMA 1, UL Type 1 enclosure drive voids NEMA 1, UL Type 1
protection while maintaining IP20 conformity. This is applicable to models 2A0004 to 2A0211, 4A0002 to 4A0165, and 5A0003 to 5A0242.
A.3 Drive Specifications
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
245
A
Specifications

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
