YASKAWA A1000 Series

n
Flange Type Heat Loss Data
Table 2.14
Models 2A0056, 4A0038, and 5A0017 and 5A0022
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz) HD (Fc = 8 kHz)
Internal External Total Internal External Total
2A0056 200 175.4 370.7 546.1 129.9 280.2 410.1 5.9 (13.0)
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz) HD (Fc = 8 kHz)
Internal External Total Internal External Total
4A0038 400 181.6 339.6 521.2 140.8 262.6 403.4 6.0 (13.2)
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz) HD (Fc = 8 kHz)
Internal External Total Internal External Total
5A0017
600
146.7 96.6 243.3 67.5 144.7 212.2 6.0 (13.2)
5A0022 178.3 99.4 277.7 81.1 203.8 284.9 6.0 (13.2)
2.2 Flange Type Enclosure (NEMA 12 Backside) Dimensions & Heat Loss
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
53
2
Mechanical Installation
