YASKAWA A1000 Series

n
Flange Type Panel Cutout Dimensions for External Heatsink Mounting
6.26
[159.0]
5.51
[140.0]
0.23
[5.8]
(6)-#10
[M5]
CUTOUT
4.72
[120.0]
0.35
[8.8]
0.83
[21.2]
8.43
[214.0]
NOTES:
1. CUTOUT TOLERANCES:
=/- 0.02 in. [0.5 mm]
2. EXPOSED HEATSINK
RECOMMENDED CLEARANCE
D=2.36 in. [60 mm] MINUS PANEL THICKNESS
5.46
[138.8]
12.6
[320.0]
10.35
[263.0]
5.46
[138.8]
Unit: in. [mm]
Figure 2.14 Models 2A0030 and 2A0040, 4A0018 and 4A0023, and 5A0011
2.2 Flange Type Enclosure (NEMA 12 Backside) Dimensions & Heat Loss
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
49
2
Mechanical Installation
