YASKAWA A1000 Series

Table 4.15 Derated Torque Characteristics, Settings 4 to 7
Setting = 4 50 Hz Setting = 5 50 Hz Setting = 6 60 Hz Setting = 7 60 Hz
0
8
200
1.3 25 50
35
Voltage (V)
Frequency (Hz)
0
9
200
1.3 25 50
50
Voltage (V)
Frequency (Hz)
0
8
200
1.5 30 60
35
Voltage (V)
Frequency (Hz)
0
9
200
1.5 30 60
50
Voltage (V)
Frequency (Hz)
Table 4.16 High Starting Torque, Settings 8 to B
Setting = 8 50 Hz Setting = 9 50 Hz Setting = A 60 Hz Setting = B 60 Hz
0
11
200
1.3 2.5 50
19
Voltage (V)
Frequency (Hz)
0
13
200
1.3 2.5 50
24
Voltage (V)
Frequency (Hz)
0
11
200
1.5 3 60
19
Voltage (V)
Frequency (Hz)
0
15
200
1.5 3 60
24
Voltage (V)
Frequency (Hz)
Table 4.17 Rated Output Operation, Settings C to E
Setting = C 90 Hz Setting = D 120 Hz Setting = E 180 Hz
0
9
15
200
1.5 3 9060
Voltage (V)
Frequency (Hz)
0
9
15
200
1.5 3 12060
Voltage (V)
Frequency (Hz)
0
9
15
200
1.5 3 18060
Voltage (V)
Frequency (Hz)
Predefined V/f Patterns for Models 2A0030 to 2A0211 (HD), 2A0021 to 2A0169 (ND), 4A0018 to 4A0103 (HD),
4A0011 to 4A0088 (ND), 5A0011 to 5A0077 (HD), and 5A0009 to 5A0062 (ND)
The
voltage values in the following graphs are specific to 200 V class drives. Double the values for 400 V class drives. Multiply
the values by 2.875 for 600 V class drives.
Table 4.18 Rated Torque Characteristics, Settings 0 to 3, F
Setting = 0 50 Hz Setting = 1, F 60 Hz Setting = 2 60 Hz Setting = 3 72 Hz
0
7
200
1.3 2.5 50
14
Voltage (V)
Frequency (Hz)
0
7
14
200
1.5 3 60
Voltage (V)
Frequency (Hz)
Voltage (V)
Frequency (Hz)
0
7
14
200
1.5 3 6050
0
7
14
200
1.5 3 7260
Voltage (V)
Frequency (Hz)
Table 4.19 Derated Torque Characteristics, Settings 4 to 7
Setting = 4 50 Hz Setting = 5 50 Hz Setting = 6 60 Hz Setting = 7 60 Hz
Voltage (V)
Frequency (Hz)
0
6
200
1.3 25 50
35
0
7
200
1.3 25 50
50
Voltage (V)
Frequency (Hz)
Voltage (V)
Frequency (Hz)
0
6
200
1.5 30 60
35
0
7
200
1.5 30 60
50
Voltage (V)
Frequency (Hz)
4.6 Basic Drive Setup Adjustments
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
149
4
Start-Up Programming & Operation
