YASKAWA A1000 Series User Manual

Revision History
The revision dates and the numbers of the revised manuals appear on the bottom of the back cover.
MANUAL NO. TOEP C710616 41B <1>
Published in Japan July 2010
MANUAL NO. SIEP C710616 41B <2>MANUAL NO. SIEP C710616 41B <2>
Date of publication
Revision number
Date of publicationDate of publication
Date of
Publication
Revision
Number
Section Revised Content
August 2019 <6>
All Revision
Updated the information to reflect the compliance of 600 V models
with the safe disable input and European standards.
Back Cover Revision: Address
April 2016 <5>
Front Cover Revision: Revision: Format
All Revision:
Reviewed and corrected entire documentation.
Upgraded drive software version to PRG: 1021, PRG: 1022,
PRG: 1023, and PRG: 1024
Back Cover Revision: Format and address
October 2013 <4>
All Revision:
Reviewed and corrected entire documentation.
Upgraded drive software version to PRG: 1018, PRG: 1019, and
PRG: 1020
Chapter 2 Addition:
Addition: NEMA Type 1 and NEMA Type 12 External Heatsink
Mounting data
Back Cover Revision: Address
May 2012 <3>
Front Cover Revision: Format
Chapter 8 Revision: Factory Recommended Branch Circuit Protection data
Appendix A Addition: Single-Phase Derating data
Appendix D Revision: Factory Recommended Branch Circuit Protection data
All Revision:
Reviewed and corrected entire documentation.
Upgraded drive software version to PRG: 1016 and PRG: 1017
Back Cover Revision: Format and address
November 2010 <2> All
Addition:
Larger drive capacities added along with corresponding data.
Three-Phase 600 V Class: 5A0125 to 5A0242
Revision: Reviewed and corrected documentation.
July 2010 <1> All
Addition:
Larger drive capacities added along with corresponding data.
Three-Phase 400 V Class: 4A0930 and 4A1200
Three-Phase 600 V Class: 5A0041 to 5A0099
Revision:
Reviewed and corrected entire documentation.
Upgraded drive software version to PRG: 1015
April 2010 - - First Edition
This manual supports drive software versions VSA90504o and
VSA901014.
356
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
