Flange Type Heat Loss Data
Table 2.11
Models 2A0018 and 2A0021, 4A0007 to 4A0011, and 5A0006 and 5A0009
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz) HD (Fc = 8 kHz)
Internal External Total Internal External Total
2A0018
200
67.4 100.7 168.1 60.0 77.0 137.0 3.7 (8.1)
2A0021 83.3 138.4 221.7 67.4 100.7 168.1 3.7 (8.1)
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz) HD (Fc = 8 kHz)
Internal External Total Internal External Total
4A0007
400
59.0 62.1 121.1 53.0 47.7 100.7 3.6 (7.9)
4A0009 60.4 65.8 126.2 55.3 53.1 108.4 3.7 (8.1)
4A0011 73.0 88.7 161.7 61.0 68.5 129.5 3.7 (8.1)
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz) HD (Fc = 8 kHz)
Internal External Total Internal External Total
5A0006
600
43.7 28.1 71.8 27.0 53.0 80.0 3.7 (8.1)
5A0009 68.9 43.4 112.3 36.4 78.7 115.1 3.7 (8.1)
2.2 Flange Type Enclosure (NEMA 12 Backside) Dimensions & Heat Loss
