Flange Type Heat Loss Data
Table 2.15
Models 2A0069 and 2A0081, 4A0044, and 5A0027 and 5A0032
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz) HD (Fc = 8 kHz)
Internal External Total Internal External Total
2A0069
200
204.5 491.3 695.8 162.8 394.9 557.7 9.1 (20.0)
2A0081 257.4 527.4 784.8 220.9 459.8 680.7 10.0 (22.0)
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz) HD (Fc = 8 kHz)
Internal External Total Internal External Total
4A0044 400 208.9 389.6 598.5 179.4 329.8 509.2 8.7 (19.1)
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz) HD (Fc = 8 kHz)
Internal External Total Internal External Total
5A0027
600
227.2 132.1 359.3 113.9 267.2 381.1 8.7 (19.1)
5A0032 279.9 141.6 421.5 132.2 332.9 465.1 8.7 (19.1)
2.2 Flange Type Enclosure (NEMA 12 Backside) Dimensions & Heat Loss
