YASKAWA CR700

Startup Procedure and Test Run
3
3.4 Keypad Operation
YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual 173
9. Push or to select the hour or minute, then push or to change the value.
10. When you are done setting the time, push .
The procedure for setting the date and time is complete.
◆ Disable the Initial Setup Screen
Do the steps in this procedure to not show the initial start-up screen when the drive is energized.
1. Push (Home) to show the HOME screen.
Note:
• When the drive is in HOME Mode, the screen shows [Home] in the upper right-hand corner of the screen.
• If the screen does not show [Home] for , push (Back), and then push to show [Home].
2. Push (Menu).
3. Push / to select [Initial Setup], then push .
4. Push / to select [Show Initial Setup Screen], then push .
