10.13 o: Keypad-Related Settings
524 YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual
10.13 o: Keypad-Related Settings
◆ o1: Keypad Display
No.
(Hex.)
Name Description
Default
(Range)
Ref.
o1-01
(0500)
RUN
User Monitor Selection
Sets the U monitor for the Drive Mode. This parameter is only available with an LED
keypad.
Note:
You cannot select U2 Monitors [Fault Trace] or U3 Monitors [Fault History].
106
(104 - 999)
782
o1-02
(0501)
RUN
Monitor Selection at
Power-up
Sets the monitor item that the keypad screen shows after you energize the drive. Refer
to “U: Monitors” for information about the monitor items that the keypad screen can
show. This parameter is only available with an LED keypad.
1 : Frequency Reference (U1-01)
2 : Direction
3 : Output Frequency (U1-02)
4 : Output Current (U1-03)
5 : User Monitor (o1-01)
1
(1 - 5)
782
o1-03
(0502)
Frequency Display Unit
Selection
Sets the display units for the frequency reference and output frequency.
0 : 0.01 Hz
1 : 0.01% (100% = E1-04)
2 : min
-1
(r/min) units
3 : User Units (o1-10 & o1-11)
4 : 0.01m/min
Determined by A1-02
(0 - 4)
782
o1-04
(0503)
V/f Pattern Display Unit
Sets the setting unit for parameters that set the V/f pattern frequency.
0 : Hz
1 : min
-1
(r/min) units
Determined by A1-02
(0, 1)
783
o1-05
(0504)
RUN
LCD Contrast
Adjustment
Sets the contrast of the LCD display on the keypad.
5
(0 - 10)
783
o1-10
(0520)
User Units Maximum
Value
Sets the value that the drive shows as the maximum output frequency.
Determined by o1-03
(1 - 60000)
784
o1-11
(0521)
User Units Decimal
Position
Sets the number of decimal places for frequency reference and monitor values.
0 : No Decimal Places (XXXXX)
1 : One Decimal Places (XXXX.X)
2 : Two Decimal Places (XXX.XX)
3 : Three Decimal Places (XX.XXX)
Determined by o1-03
(0 - 3)
784
o1-20
(0575)
Sheave Diameter
Sets the sheave diameter.
400 mm
(100 - 2000 mm)
784
o1-21
(0576)
Roping Ratio
Sets the roping ratio.
1 : 1:1
2 : 1:2
3 : 1:3
4 : 1:4
2
(1 - 4)
784
o1-22
(0577)
Gear Ratio
Sets the gear ratio.
14.00
(0.10 - 50.00)
784
o1-24 to o1-35:
(11AD - 11B8)
RUN
Custom Monitor 1 to 12
Sets a maximum of 12 monitors as user monitors. This parameter is only available when
using an LCD keypad.
o1-24: 101
o1-25: 102
o1-26: 103
o1-27 to o1-35: 0
(0, 101 - 999)
784
o1-36
(11B9)
RUN
LCD Backlight
Brightness
Sets the intensity of the LCD keypad backlight.
3
(1 - 5)
785
o1-37
(11BA)
RUN
LCD Backlight ON/OFF
Selection
Sets the automatic shut off function for the LCD backlight.
0 : OFF
1 : ON
1
(0, 1)
785
