10.16 U: Monitors
548 YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual
No.
(Hex.)
Name Description MFAO Signal Level
U4-24
(1581)
Number of Runs (Low)
Displays the lower 4 digits of the drive run count.
Note:
The drive run count appears as an 8-digit number. The upper 4 digits of U4-25 [Number of
Runs(High)] and the lower 4 digits of U4-24 appear.
No signal output available
U4-25
(1582)
Number of Runs(High)
Displays the upper 4 digits of the drive run count.
Note:
The drive run count appears as an 8-digit number. The upper 4 digits of U4-25 and the lower
4 digits of U4-24 [Number of Runs (Low)] appear.
No signal output available
U4-52
(1592)
Torque Ref from Comm
Displays the torque limit given to the drive via a serial communication option card or via
MEMOBUS/Modbus communications as a decimal number.
Unit: 0.1%
No signal output available
U4-53
(1593)
Num of Driv 1 (Low)
Displays the lower 4 digits of the cumulative motor 1 startup count.
Note:
The startup count 1 appears as an 8-digit number. The upper 4 digits of U4-54 [Num of Driv 1
(High)] and the lower 4 digits of U4-53 appear. The maximum count value is 10,000,000.
No signal output available
U4-54
(1594)
Num of Driv 1 (High)
Displays the upper 4 digits of the cumulative motor 1 startup count.
Note:
The startup count 1 appears as an 8-digit number. The upper 4 digits of U4-54 and the lower 4
digits of U4-53 [Num of Driv 1 (Low)] appear. The maximum count value is 10,000,000.
No signal output available
U4-55
(1595)
Num of Driv 2 (Low)
Displays the lower 4 digits of the cumulative motor 2 startup count.
Note:
The startup count 2 appears as an 8-digit number. The upper 4 digits of U4-56 [Num of Driv 2
(High)] and the lower 4 digits of U4-55 appear. The maximum count value is 10,000,000.
No signal output available
U4-56
(1596)
Num of Driv 2 (High)
Displays the upper 4 digits of the cumulative motor 2 startup count.
Note:
The startup count 2 appears as an 8-digit number. The upper 4 digits of U4-56 and the lower 4
digits of U4-55 [Num of Driv 2 (Low)] appear. The maximum count value is 10,000,000.
No signal output available
U4-57
(1597)
Num of Driv 3 (Low)
Displays the lower 4 digits of the cumulative motor 3 startup count.
Note:
The startup count 3 appears as an 8-digit number. The upper 4 digits of U4-58 [Num of Driv 3
(High)] and the lower 4 digits of U4-57 appear. The maximum count value is 10,000,000.
No signal output available
U4-58
(1598)
Num of Driv 3 (High)
Displays the upper 4 digits of the cumulative motor 3 startup count.
Note:
The startup count 3 appears as an 8-digit number. The upper 4 digits of U4-58 and the lower 4
digits of U4-57 [Num of Driv 3 (Low)] appear. The maximum count value is 10,000,000.
No signal output available
◆ U6: Operation Status Monitors
No.
(Hex.)
Name Description MFAO Signal Level
U6-01
(0051)
Iq Secondary Current
Shows the value calculated for the motor secondary current (q-Axis) as a percentage of the motor
rated secondary current.
Unit: 0.1%
10 V: Motor secondary
rated current (0 V to +10 V)
U6-02
(0052)
Id ExcitationCurrent
Shows the value calculated for the motor excitation current (d-Axis) as a percentage of the motor
rated secondary current.
Unit: 0.1%
10 V: Motor secondary
rated current (0 V to +10 V)
U6-03
(0054)
ASR Input
Shows the ASR input value as a percentage of the maximum frequency.
Unit: 0.01%
10 V: Maximum frequency
(0 V to +10 V)
U6-04
(0055)
ASR Output
Shows the ASR output value as a percentage of the motor rated secondary current.
Unit: 0.01%
10 V: Motor secondary
rated current (0 V to +10 V)
U6-05
(0059)
OutputVoltageRef: Vq
Shows the drive internal voltage reference for motor secondary current control (q-Axis).
Unit: 0.1 V
200 V Class: 10 V = 200
Vrms
400 V Class: 10 V = 400
Vrms
(0 V to +10 V)
