Page #547 background imageLoading...
Page #547 background image
Parameter List
10
10.16 U: Monitors
YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual 547
No.
(Hex.)
Name Description MFAO Signal Level
U4-21
(07DD)
Run Command Source
Displays the Run command source that is currently selected.
The Run command source is presented as XY-nn in the following manner.
X: External Reference 1/2 Selection [H1-xx = 2] selection status
1: b1-02 [Run Command Selection 1]
2: b1-16 [Run Command Selection 2]
Y: Run command source
0: Keypad
1: Control circuit terminal
3: MEMOBUS/Modbus communications
4: Communication option card
nn: Run command limit status data
00: No limit status.
01: The Run command was left ON when the drive stopped in the Programming Mode.
02: The Run command was left ON when switching from LOCAL Mode to REMOTE Mode.
03: The Run command is in standby after the drive was energized until the soft charge bypass
contactor turns ON.
Note:
When the soft charge bypass contactor does not turn ON after 10 s have passed, Uv1 [DC Bus
Undervoltage] or Uv [Undervoltage] is detected.
04: Restart after run stop is prohibited.
05: Fast stop has been executed using the MFDI terminal. Or, the motor has ramped to stop by
pressing the STOP key on the keypad.
06: b1-17 = 0 [Run Command at Power Up = Disregard Existing RUN Command] is set.
07: During baseblock while coast to stop with timer.
08: Frequency reference is below E1-09 [Minimum Output Frequency] during baseblock.
09: Waiting for the Enter command from PLC.
No signal output available
U4-22
(07DE)
Modbus CmdData (hex)
Displays the operation signal (register No. 0001H) from MEMOBUS/Modbus communications to
the drive as a four-digit hexadecimal number (zero suppress).
The operation signal is displayed in the following way.
bit 0 : Forward run/Stop
bit 1 : Reverse run/Stop
bit 2 : External Fault
bit 3 : Fault Reset
bit 4 : Multi-function input 1
bit 5 : Multi-function input 2
bit 6 : Multi-function input 3
bit 7 : Multi-function input 4
bit 8 : Multi-function input 5
bit 9 : Multi-function input 6
bit A : Multi-function input 7
bit B : Multi-function input 8
bit C : Multi-function input 9
bit D : Multi-function input 10
bit E : Not used (normal value of 0).
bit F : Not used (normal value of 0).
No signal output available
U4-23
(07DF)
Option CmdData (hex)
Displays the operation signal (register No. 0001H) from communication option to the drive as a
four-digit hexadecimal number.
The operation signal is displayed in the following way.
bit 0 : Forward run/Stop
bit 1 : Reverse run/Stop
bit 2 : External Fault
bit 3 : Fault Reset
bit 4 : Multi-function input 1
bit 5 : Multi-function input 2
bit 6 : Multi-function input 3
bit 7 : Multi-function input 4
bit 8 : Multi-function input 5
bit 9 : Multi-function input 6
bit A : Multi-function input 7
bit B : Multi-function input 8
bit C : Multi-function input 9
bit D : Multi-function input 10
bit E : Not used (normal value of 0).
bit F : Not used (normal value of 0).
No signal output available
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
