11.8 H: Terminal Functions
704 YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual
◆ H2 MFDO Parameters
■ H2-01: Term M1-M2 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H2-01
(040B)
Term M1-M2 Function
Selection
Sets the function for MFDO terminal M1-M2.
21
(0 - 1FF)
Note:
Set this parameter to F when not using the terminal or to use the terminal in through mode.
■ H2-02: Term M3-M4 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H2-02
(040C)
Term M3-M4 Function
Selection
Sets the function for MFDO terminal M3-M4.
0
(0 - 1FF)
Note:
Set this parameter to F when not using the terminal or to use the terminal in through mode.
■ H2-03: Term M5-M6 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H2-03
(040D)
Term M5-M6 Function
Selection
Sets the function for MFDO terminal M5-M6.
2
(0 - 1FF)
Note:
Set this parameter to F when not using the terminal or to use the terminal in through mode.
■ H2-04: Term P1-C1 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H2-04
(040E)
Term P1-C1 Function
Selection
Sets the function for MFDO terminal P1-C1.
6
(0 - 1FF)
Note:
Set this parameter to F when not using the terminal or to use the terminal in through mode.
■ H2-05: Term P2-C2 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H2-05
(040F)
Term P2-C2 Function
Selection
Sets the function for MFDO terminal P2-C2.
10
(0 - 1FF)
Note:
Set this parameter to F when not using the terminal or to use the terminal in through mode.
■ H2-06: Watt Hour Output Unit Selection
No.
(Hex.)
Name Description
Default
(Range)
H2-06
(0437)
Watt Hour Output Unit
Selection
Sets the unit for the output signal when H2-01 to H2-05 = 39 [MFDO Function Selection = Watt
Hour Pulse Output].
0
(0 - 4)
This output is input to the Watt hour meter or PLC via a 200 ms pulse signal. Each pulse is output by the kWh unit
selected by H2-06.
