Parameter Details
11
11.7 F: Options
YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual 651
11.7 F: Options
F parameters are used to set option cards, which function as interfaces for encoders, analog I/O, digital I/O, and
fieldbus communication.
◆ F1: Encoder Option Setup
F1 parameters are used to set the operation of and protective function for the encoder option card. The following
table lists the setting parameters available for each option card.
Refer to the instruction manual packaged with the encoder option card for more information on installing, wiring,
and setting the encoder option cards.
WARNING! Sudden Movement Hazard. Do test runs and examine the drive to make sure that the command references are
correct. If you set the command reference incorrectly, it can cause damage to the drive or serious injury or death.
WARNING! Sudden Movement Hazard. Make sure that the host controller circuitry has correct safety design that will let you
keep control of the motor if the drive loses speed feedback. If you do not have control of the motor, it can cause serious injury or
death.
Table 11.18 Encoder Option Card Setting Parameters
Setting Parameter
Encoder Option Card
PG-B3 PG-X3 PG-RT3
F1-01 x x -
F1-02 x x x
F1-03 x x x
F1-04 x x x
F1-05 x x x
F1-06 x x -
F1-08 x x x
F1-09 x x x
F1-10 x x x
F1-11 x x x
F1-12
*1
x x -
F1-13
*1
x x -
F1-14 x x x
F1-20 - x -
F1-21 x x -
F1-30 x x -
F1-31
*2
x x -
F1-32
*2
x x -
F1-33
*1 *2
x x -
F1-34
*1 *2
x x -
F1-35
*2
x x -
F1-36 - x -
F1-37
*2
x x -
Number of cards that can be installed in a
drive
2 2 1
*1 Parameters set when using the Closed Loop V/f Control method.
*2 Parameters to set an option card connected to CN5-B.
■ F1-01: Encoder 1 Pulse Count (PPR)
No.
(Hex.)
Name Description
Default
(Range)
F1-01
(0380)
Encoder 1 Pulse Count
(PPR)
Sets the number of output pulses per revolution of the encoder.
1024
(1 - 60000 ppr)
