11.2 A: Initialization Parameters
582 YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual
Analog Input FilterTime Constant
When b1-01 = 1 [Frequency Reference Selection 1 = Analog Input], it adds noise to the analog frequency
reference during run.
• Minimize the effects of noise.
• Change H3-13 [Analog Input FilterTime Constant] to a range of 0.01 s to 0.10 s.
Startup Current Check
When you do a test run, set L8-41 =1 [High Current Alarm Selection = Enabled] and use U4-13 [Peak Hold
Current] and a clamp ammeter with the machine under load and not under load to check the motor current during
start up.
If the motor torque is not sufficient during start up or if the timing between the motor and the holding brake is
unsatisfactory and causes the motor to lock, a large quantity of current will flow. In these conditions, adjust the
parameters again and decrease the load to decrease the current to less than 150%. If the current flow is more than
150% of the drive rated current, the heat stress on the IGBTs will decrease the service life of drive parts.
To decrease the effects of heat stress, decrease the carrier frequency of the drive to 2.0 kHz to 2.5 kHz for
applications where low audible noise is not necessary.
■ A1-11: Firmware Update Lock
No.
(Hex.)
Name Description
Default
(Range)
A1-11
(111D)
Expert
Firmware Update Lock
Protects the drive firmware. When you enable the protection, you cannot update the drive
firmware.
0
(0, 1)
0 : Disabled
Lock is disabled.
1 : Enabled
Lock is enabled.
■ A1-12: Bluetooth ID
No.
(Hex.)
Name Description
Default
(Range)
A1-12
(1564)
Bluetooth ID
Sets the password necessary to use Bluetooth to control the drive with a smartphone or tablet.
1915
(0000 - 9999)
■ A1-13: All Function Parameter Display
No.
(Hex.)
Name Description
Default
(Range)
A1-13
(156F)
All Function Parameter
Display
Shows and hides applicable parameters.
1
(0, 1)
0 : Disabled
1 : Enabled
◆ A2: User Parameters
You can register frequently used parameters and recently changed parameters here to access them quickly. You
can show the registered parameters in [User Custom Parameters] in the main menu.
■ A2-01 to A2-32: User Parameters 1 to 32
No.
(Hex.)
Name Description
Default
(Range)
A2-01 to A2-32
(0106 - 0125)
User Parameters 1 to 32
The user can select up to 32 parameters for the drive and assign them to parameters A2-01 to A2-
32. The [User Parameters] section of the keypad main menu shows the set parameters. You can
immediately access these saved parameters.
Determined by A1-06
(A1-00 to S-xx)
Note:
• Settings for A2-01 to A2-32 vary depending on the value selected for A1-06 [Application Preset].
• You must set A1-01 = 1 [Access Level Selection = User Parameters] to access parameters A2-01 to A2-32.
