YASKAWA CR700 Technical Manual

Parameter List
10
10.20 Parameters Changed by o2-04 [Drive Model (KVA) Selection]
YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual 557
10.20 Parameters Changed by o2-04 [Drive Model (KVA)
Selection]
The values for the parameters in these tables depend on the values for the parameter o2-04. The values of the
default settings change as the setting of o2-04 changes.
◆ 200 V Class
No. Name Unit Default
- Drive Model - 2003 2005 2008
o2-04
Drive Model (KVA)
Selection
Hex. 62 63 65
Motor 1: E2-11
Motor 2: E4-11
Motor 3: E7-31
Motor Rated Power kW 0.4 0.75 1.5
Motor 1: C5-17
Motor 2: C5-37
Motor Inertia kgm
2
0.0015 0.0028 0.0068
C6-02 Carrier Frequency Selection - 1 1 1
E1-01 Input AC Supply Voltage V 230 230 230
Motor 1: E2-01
Motor 2: E4-01
Motor 3: E7-21
Motor Rated Current (FLA) A 1.9 3.3 6.2
Motor 1: E2-02
Motor 2: E4-02
Motor Rated Slip Hz 2.9 2.5 2.6
Motor 1: E2-03
Motor 2: E4-03
Motor No-Load Current A 1.2 1.8 2.8
Motor 1: E2-05
Motor 2: E4-05
Motor 3: E7-25
Motor Line-to-Line
Resistance
Ω 9.842 5.156 1.997
Motor 1: E2-06
Motor 2: E4-06
Motor Leakage Inductance % 18.2 13.8 18.5
Motor 1: E2-10
Motor 2: E4-10
Motor Iron Loss W 14 26 53
L2-03 Minimum Baseblock Time s 0.2 0.3 0.4
L2-05
Undervoltage Detection Lvl
(Uv1)
- 190 190 190
L3-24
Motor Accel Time @ Rated
Torque
s 0.178 0.142 0.166
L8-02 Overheat Alarm Level °C 115 115 115
L8-09
Output Ground Fault
Detection
- 1 1 1
L8-38
Carrier Frequency
Reduction
- 2 2 2
L8-39
Carrier Freq Reduction
during oL
- 2 2 2
n1-01
Hunting Prevention
Selection
- 1 1 1
n1-03
Hunting Prevention Time
Constant
ms 10 10 10
n1-16
Hunting Prevention High Fc
Gain
- 0.50 0.50 0.50
n2-01
Automatic Freq Regulator
Gain(F)
- 1.00 1.00 1.00
n5-02
Motor Inertia Acceleration
Time
s 0.178 0.142 0.166
