10.20 Parameters Changed by o2-04 [Drive Model (KVA) Selection]
558 YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual
No. Name Unit Default
- Drive Model - 2011 2014 2018 2025
o2-04
Drive Model (KVA)
Selection
Hex. 66 67 68 6A
Motor 1: E2-11
Motor 2: E4-11
Motor 3: E7-31
Motor Rated Power kW 2.2 3.0 3.7 5.5
Motor 1: C5-17
Motor 2: C5-37
Motor Inertia kgm
2
0.0088 0.0158 0.0158 0.026
C6-02
Carrier Frequency
Selection
- 1 1 1 1
E1-01
Input AC Supply
Voltage
V 230 230 230 230
Motor 1: E2-01
Motor 2: E4-01
Motor 3: E7-21
Motor Rated Current
(FLA)
A 8.5 11.4 14 19.6
Motor 1: E2-02
Motor 2: E4-02
Motor Rated Slip Hz 2.9 2.7 2.73 1.5
Motor 1: E2-03
Motor 2: E4-03
Motor No-Load
Current
A 3 3.7 4.5 5.1
Motor 1: E2-05
Motor 2: E4-05
Motor 3: E7-25
Motor Line-to-Line
Resistance
Ω 1.601 1.034 0.771 0.399
Motor 1: E2-06
Motor 2: E4-06
Motor Leakage
Inductance
% 18.4 19 19.6 18.2
Motor 1: E2-10
Motor 2: E4-10
Motor Iron Loss W 77 91 112 172
L2-03
Minimum Baseblock
Time
s 0.5 0.5 0.6 0.7
L2-05
Undervoltage Detection
Lvl (Uv1)
- 190 190 190 190
L3-24
Motor Accel Time @
Rated Torque
s 0.145 0.145 0.154 0.168
L8-02 Overheat Alarm Level °C 124 110 110 110
L8-09
Output Ground Fault
Detection
- 1 1 1 1
L8-38
Carrier Frequency
Reduction
- 2 2 2 2
L8-39
Carrier Freq Reduction
during oL
- 2 2 2 2
n1-01
Hunting Prevention
Selection
- 1 1 1 1
n1-03
Hunting Prevention
Time Constant
ms 10 10 10 10
n1-16
Hunting Prevention
High Fc Gain
- 0.50 0.50 0.50 0.50
n2-01
Automatic Freq
Regulator Gain(F)
- 1.00 1.00 1.00 1.50
n5-02
Motor Inertia
Acceleration Time
s 0.145 0.145 0.154 0.168
No. Name Unit Default
- Drive Model - 2033 2047 2060 2075
o2-04
Drive Model (KVA)
Selection
Hex. 6B 6D 6E 6F
Motor 1: E2-11
Motor 2: E4-11
Motor 3: E7-31
Motor Rated Power kW 7.5 11 15 18.5
Motor 1: C5-17
Motor 2: C5-37
Motor Inertia kgm
2
0.037 0.053 0.076 0.138
C6-02
Carrier Frequency
Selection
- 1 1 1 1
E1-01
Input AC Supply
Voltage
V 230 230 230 230
