10.20 Parameters Changed by o2-04 [Drive Model (KVA) Selection]
YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual 559
No. Name Unit Default
- Drive Model - 2033 2047 2060 2075
o2-04
Drive Model (KVA)
Selection
Hex. 6B 6D 6E 6F
Motor 1: E2-11
Motor 2: E4-11
Motor 3: E7-31
Motor Rated Power kW 7.5 11 15 18.5
Motor 1: E2-01
Motor 2: E4-01
Motor 3: E7-21
Motor Rated Current
(FLA)
A 26.6 39.7 53 65.8
Motor 1: E2-02
Motor 2: E4-02
Motor Rated Slip Hz 1.3 1.7 1.6 1.67
Motor 1: E2-03
Motor 2: E4-03
Motor No-Load
Current
A 8 11.2 15.2 15.7
Motor 1: E2-05
Motor 2: E4-05
Motor 3: E7-25
Motor Line-to-Line
Resistance
Ω 0.288 0.23 0.138 0.101
Motor 1: E2-06
Motor 2: E4-06
Motor Leakage
Inductance
% 15.5 19.5 17.2 20.1
Motor 1: E2-10
Motor 2: E4-10
Motor Iron Loss W 262 245 272 505
L2-03
Minimum Baseblock
Time
s 0.8 0.9 1 1
L2-05
Undervoltage Detection
Lvl (Uv1)
- 190 190 190 190
L3-24
Motor Accel Time @
Rated Torque
s 0.175 0.265 0.244 0.317
L8-02 Overheat Alarm Level °C 110 115 120 133
L8-09
Output Ground Fault
Detection
- 1 1 1 1
L8-38
Carrier Frequency
Reduction
- 2 2 2 2
L8-39
Carrier Freq Reduction
during oL
- 2 2 2 2
n1-01
Hunting Prevention
Selection
- 1 2 2 2
n1-03
Hunting Prevention
Time Constant
ms 10 10 10 10
n1-16
Hunting Prevention
High Fc Gain
- 0.50 0.50 0.50 0.50
n2-01
Automatic Freq
Regulator Gain(F)
- 1.50 1.00 1.50 1.00
n5-02
Motor Inertia
Acceleration Time
s 0.175 0.265 0.244 0.317
No. Name Unit Default
- Drive Model - 2088 2115 2145 2180
o2-04
Drive Model (KVA)
Selection
Hex. 70 72 73 74
Motor 1: E2-11
Motor 2: E4-11
Motor 3: E7-31
Motor Rated Power kW 22 30 37 45
Motor 1: C5-17
Motor 2: C5-37
Motor Inertia kgm
2
0.165 0.220 0.273 0.333
C6-02
Carrier Frequency
Selection
- 1 1 1 1
E1-01
Input AC Supply
Voltage
V 230 230 230 230
Motor 1: E2-01
Motor 2: E4-01
Motor 3: E7-21
Motor Rated Current
(FLA)
A 77.2 105 131 160
Motor 1: E2-02
Motor 2: E4-02
Motor Rated Slip Hz 1.7 1.8 1.33 1.6
To Next Page
