10.20 Parameters Changed by o2-04 [Drive Model (KVA) Selection]
560 YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual
No. Name Unit Default
- Drive Model - 2088 2115 2145 2180
o2-04
Drive Model (KVA)
Selection
Hex. 70 72 73 74
Motor 1: E2-11
Motor 2: E4-11
Motor 3: E7-31
Motor Rated Power kW 22 30 37 45
Motor 1: E2-03
Motor 2: E4-03
Motor No-Load
Current
A 18.5 21.9 38.2 44
Motor 1: E2-05
Motor 2: E4-05
Motor 3: E7-25
Motor Line-to-Line
Resistance
Ω 0.079 0.064 0.039 0.03
Motor 1: E2-06
Motor 2: E4-06
Motor Leakage
Inductance
% 19.5 20.8 18.8 20.2
Motor 1: E2-10
Motor 2: E4-10
Motor Iron Loss W 538 699 823 852
L2-03
Minimum Baseblock
Time
s 1 1.1 1.1 1.2
L2-05
Undervoltage Detection
Lvl (Uv1)
- 190 190 190 190
L3-24
Motor Accel Time @
Rated Torque
s 0.355 0.323 0.32 0.387
L8-02 Overheat Alarm Level °C 105 115 105 105
L8-09
Output Ground Fault
Detection
- 1 1 1 1
L8-38
Carrier Frequency
Reduction
- 2 2 2 2
L8-39
Carrier Freq Reduction
during oL
- 2 2 2 2
n1-01
Hunting Prevention
Selection
- 2 2 2 2
n1-03
Hunting Prevention
Time Constant
ms 10 10 10 10
n1-16
Hunting Prevention
High Fc Gain
- 0.50 0.50 0.50 0.50
n2-01
Automatic Freq
Regulator Gain(F)
- 1.00 1.00 1.00 1.00
n5-02
Motor Inertia
Acceleration Time
s 0.355 0.323 0.32 0.387
No. Name Unit Default
- Drive Model - 2215 2283 2346 2415
o2-04
Drive Model (KVA)
Selection
Hex. 75 76 77 78
Motor 1: E2-11
Motor 2: E4-11
Motor 3: E7-31
Motor Rated Power kW 55 75 90 110
Motor 1: C5-17
Motor 2: C5-37
Motor Inertia kgm
2
0.49 0.90 1.10 1.90
C6-02
Carrier Frequency
Selection
- 1 1 1 1
E1-01
Input AC Supply
Voltage
V 230 230 230 230
Motor 1: E2-01
Motor 2: E4-01
Motor 3: E7-21
Motor Rated Current
(FLA)
A 190 260 260 260
Motor 1: E2-02
Motor 2: E4-02
Motor Rated Slip Hz 1.43 1.39 1.39 1.39
Motor 1: E2-03
Motor 2: E4-03
Motor No-Load
Current
A 45.6 72 72 72
Motor 1: E2-05
Motor 2: E4-05
Motor 3: E7-25
Motor Line-to-Line
Resistance
Ω 0.022 0.023 0.023 0.023
