Page #535 background imageLoading...
Page #535 background image
Parameter List
10
10.14 S: Crane Parameters
YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual 535
S5: Overload Detection
No.
(Hex.)
Name Description
Default
(Range)
Ref.
S5-01
(06B0)
OverL Detect Operation
Select 1
Sets whether to enable or disable overload detection, the detection conditions, and the
drive operation after detection of faults.
0 : Disabled
1 : oL5 @ Speed Agree - Alarm only
2 : oL5 @ RUN - Alarm only
3 : oL5 @ Speed Agree - Alarm only2
4 : oL5 @ RUN - Alarm only2
5 : oL5 @ Speed Agree - Fault
6 : oL5 @ RUN - Fault
0
(0 - 6)
213
226
S5-02
(06B1)
OverL Detect Operation
Select 1
Sets the level to trigger an overload.
150%
(0 - 300%)
213
226
S5-03
(06B2)
Overload Detection
Time 1
Sets the overload detection time 1.
0.1 s
(0.0 - 10.0 s)
213
226
S5-04
(06B3)
OverL Detect Operation
Select 2
Sets whether to enable or disable overload detection, the detection conditions, and the
drive operation after detection of faults.
0 : Disabled
1 : oL5 @ Speed Agree - Alarm only
2 : oL5 @ RUN - Alarm only
3 : oL5 @ Speed Agree - Alarm only2
4 : oL5 @ RUN - Alarm only2
5 : oL3 @ Speed Agree - Fault
6 : oL3 @ RUN - Fault
0
(0 - 6)
213
226
S5-05
(06B4)
Overload Detection
Torque 2
Sets the level to trigger an overload.
150%
(0 - 300%)
213
226
S5-06
(06B5)
Overload Detection
Time 2
Sets the overload detection time 2.
0.1 s
(0.0 - 10.0 s)
213
226
S6: Overtorque Detection
No.
(Hex.)
Name Description
Default
(Range)
Ref.
S6-01
(06B6)
OverT Detect Operation
Select 1
Sets whether to enable or disable overtorque detection, the detection conditions, and the
drive operation after detection of faults.
0 : Disabled
1 : oL3 @ Speed Agree - Alarm only
2 : oL3 @ RUN - Alarm only
3 : oL3 @ Speed Agree - Fault
4 : oL3 @ RUN - Fault
5 : oL3 @ Speed Agree - Alarm only2
6 : oL3 @ RUN - Alarm only2
0
(0 - 6)
214
226
S6-02
(06B7)
Overtorque Detection
Level 1
Sets the level to trigger an overtorque.
150%
(0 - 300%)
214
226
S6-03
(06B8)
Overtorque Detection
Time 1
Sets the overtorque detection time 1.
0.1 s
(0.0 - 10.0 s)
214
226
S6-04
(06B9)
OverT Detect Operation
Select 2
Sets whether to enable or disable overtorque detection, the detection conditions, and the
drive operation after detection of faults.
0 : Disabled
1 : oL3 @ Speed Agree - Alarm only
2 : oL3 @ RUN - Alarm only
3 : oL3 @ Speed Agree - Fault
4 : oL3 @ RUN - Fault
5 : oL3 @ Speed Agree - Alarm only2
6 : oL3 @ RUN - Alarm only2
0
(0 - 6)
214
226
S6-05
(06BA)
Overtorque Detection
Level 2
Sets the level to trigger an overtorque.
150%
(0 - 300%)
214
226
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
