10.12 n: Special Adjustment
522 YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual
◆ n3: Overexcitation Deceleration
No.
(Hex.)
Name Description
Default
(Range)
Ref.
n3-13
(0531)
OverexcitationBraking
(OEB) Gain
Sets the gain value that the drive multiplies by the V/f pattern output value during
overexcitation deceleration to calculate the overexcitation level.
1.10
(1.00 - 1.40)
773
n3-14
(0532)
Expert
OEB High Frequency
Injection
Sets the function that injects harmonic signals during overexcitation deceleration.
0 : Disabled
1 : Enabled
0
(0, 1)
773
n3-21
(0579)
HSB Current
Suppression Level
Sets the upper limit of the current that is suppressed at the time of overexcitation
deceleration as a percentage of the drive rated current.
100%
(0 - 150%)
773
n3-23
(057B)
Overexcitation Braking
Operation
Sets the direction of motor rotation where the drive will enable overexcitation.
0 : Disabled
1 : Enabled Only when Rotating FWD
2 : Enabled Only when Rotating REV
0
(0 - 2)
774
◆ n4: Adv Open Loop Vector Tune
No.
(Hex.)
Name Description
Default
(Range)
Ref.
n4-60
(1B80)
Motoring Low Speed
Comp Gain
Sets a compensation gain to improve the control qualities for motoring loads in the low
speed range.
100.0%
(50.0 - 200.0%)
774
n4-61
(1B81)
Low Speed Comp
Frequency Level
Sets a frequency at which the settings n4-60 [Motoring Low Speed Comp Gain] and n4-
62 [Regen Low Speed Comp Gain] are enabled. When the output frequency < n4-61, the
drive adjusts the torque to agree with the settings for n4-60 and n4-62. Usually it is not
necessary to change this setting.
6.00 Hz
(0.50 - 12.00 Hz)
774
n4-62
(1B82)
Regen Low Speed Comp
Gain
Sets a compensation gain to improve the control qualities for regenerative loads in the
low speed range.
100.0 %
(50.0 - 500.0%)
774
n4-63
(1B83)
Speed
EstimateResponse@
High Freq
In high speed ranges, where the output frequency is ≥ n4-67 [SwitchingFreq
forEstimation gain], this adjusts the responsiveness of the speed estimation.
60.0
(0.1 - 300.0)
775
n4-64
(1B84)
Speed Estimate
Response@Low Freq
In low speed ranges, where 0 ≤ the output frequency, which is < n4-67 [SwitchingFreq
forEstimation gain], this adjusts the responsiveness of the speed estimation.
60.0
(0.1 - 300.0)
775
n4-65
(1B85)
Flux Estimate
Response@High Freq
In high speed ranges, where the output frequency is ≥ n4-67 [SwitchingFreq
forEstimation gain], this adjusts the responsiveness of the magnetic flux estimation.
Usually it is not necessary to change this setting.
1.00
(0.50 - 3.00)
775
n4-66
(1B86)
Flux Estimate Response
@Low Freq
Sets the responsiveness of the magnetic flux estimation in low speed ranges, where 0 ≤
the output frequency, which is < n4-67 [Estimate Gain Switchover Freq]. Usually it is
not necessary to change this setting.
1.50
(0.50 - 3.00)
775
n4-67
(1B87)
Estimate Gain
Switchover Freq
Set the switching frequency for estimation gain for each of the following: n4-63
[SpdEstimationResponseForHighFreq], n4-64 [SpdEstimationResponse forLowFreq],
n4-65 [FluxEstimationResponseForHighFrq], and n4-66
[FluxEstimationResponseForLowFreq]. Usually it is not necessary to change this
setting.
6.00 Hz
(0.00 - E1-04)
775
n4-68
(1B88)
Speed Estimation Filter
Time
Sets the primary delay time constant for the speed estimation value. Usually it is not
necessary to change this setting.
0.001 s
(0.001 - 0.010 s)
776
n4-69
(1B89)
Flux Control Response
Unifies control of magnetic flux to make motor vibrations more stable.
1.00
(0.00 - 60.00)
776
n4-70
(1B8A)
Speed Command Comp
@ Low Freq
Sets the function to make the drive more stable when it operates at low speeds. Usually
it is not necessary to change this parameter.
1.00 Hz
(0.00 - 6.00 Hz)
776
n4-71
(1B8B)
Expert
Flux Estimation Method
Sets the flux estimation method. Usually it is not necessary to change this setting.
0 : Method 1
1 : Method 2
0
(0, 1)
776
