YASKAWA CR700 Technical Manual

Parameter List
10
10.17 Parameters that Change from the Default Settings with A1-02 [Control Method Selection]
YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual 551
10.17 Parameters that Change from the Default Settings with
A1-02 [Control Method Selection]
The values for the parameters in these tables depend on the values for parameter A1-02. When you change A1-02,
the default settings will change.
◆ A1-02 = 0 to 4 [Induction Motor Control Methods]
No. Name Range Unit
Control Method (A1-02 Setting)
V/f
(0)
CL-V/f
(1)
OLV
(2)
CLV
(3)
AOLV
(4)
b2-01
DC Injection/
Zero
SpeedThreshold
0.0 - 10.0 0.1 Hz 0.5 0.5 0.5 0.5 0.5
b2-04
DC Inject
Braking Time at
Stop
0.00 - 10.00 0.01 s 0.00 0.00 0.00 0.50 0.00
C1-11
Accel/Decel
Time Switchover
Freq
0.0 - 400.0 0.1 Hz 0.0 0.0 0.0 0.0 0.0
C2-01
S-Curve Time @
Start of Accel
0.00 - 10.00 0.01 s 0.20 0.20 0.20 0.20 0.20
C3-01
Slip
Compensation
Gain
0.0 - 2.5 0.1 0.0 - 1.0 1.0 0.1
C3-02
Slip
Compensation
Delay Time
0 - 10000 1 ms 2000 - 200 - -
C4-01
Torque
Compensation
Gain
0.00 - 2.50 0.01 1.00 1.00 1.00 - -
C4-02
Torque
Compensation
Delay Time
0 - 10000 1 ms 200 200 20 - -
C4-13
Torque Comp
Delay Time
Select 1
0 - 60000 1 ms 200 200 20 - 20
C4-15
Torque Comp
Delay Time
Select 2
0 - 60000 1 ms 200 200 20 - 20
C4-16
Torque Comp
Delay Time
Select 3
0 - 60000 1 ms 200 200 20 - 20
C5-01
ASR
Proportional
Gain 1
0.00 - 300.00 0.01 - 0.20 - 20.00 10.00
C5-02
ASR Integral
Time 1
0.000 - 60.000 0.001 s - 0.200 - 0.500 0.500
C5-03
ASR
Proportional
Gain 2
0.00 - 300.00 0.01 - 0.02 - 20.00 10.00
C5-04
ASR Integral
Time 2
0.000 - 10.000 0.001 s - 0.050 - 0.500 0.500
C5-06 ASR Delay Time 0.000 - 0.500 0.001 s - - - 0.004 0.004
C5-07
ASR Gain
Switchover
Frequency
0.0 - 400.0 0.1 Hz 0.0 0.0 0.0 0.0 0.0
C6-02
Carrier
Frequency
Selection
1 - F 1 1 1 1 1 1
d3-01
Jump Frequency
1
0.0 - 400.0 0.1 Hz 0.0 0.0 0.0 0.0 0.0
d3-02
Jump Frequency
2
0.0 - 400.0 0.1 Hz 0.0 0.0 0.0 0.0 0.0
d3-03
Jump Frequency
3
0.0 - 400.0 0.1 Hz 0.0 0.0 0.0 0.0 0.0
d3-04
Jump Frequency
Width
0.0 - 20.0 0.1 Hz 1.0 1.0 1.0 1.0 1.0
