10.17 Parameters that Change from the Default Settings with A1-02 [Control Method Selection]
552 YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual
No. Name Range Unit
Control Method (A1-02 Setting)
V/f
(0)
CL-V/f
(1)
OLV
(2)
CLV
(3)
AOLV
(4)
E1-04
Maximum
Output
Frequency
40.0 - 400.0 0.1 Hz 50.0
*1
50.0
*1
50.0 50.0 50.0
E1-05
Maximum
Output Voltage
0.0 - 255.0
*2
0.1 V 200.0
*1
200.0
*1
200.0 200.0 200.0
E1-06 Base Frequency 0.0 - 400.0 0.1 Hz 50.0
*1
50.0
*1
50.0 50.0 50.0
E1-07
Mid Point A
Frequency
0.0 - 400.0 0.1 Hz 2.5
*1
2.5
*1
3.0 - 0.0
E1-08
Mid Point A
Voltage
0.0 - 255.0
*2
0.1 V 15.0
*1
15.0
*1
14.4 - 0.0
E1-09
Minimum Output
Frequency
0.0 - 400.0 0.1 Hz 1.3
*1
1.3
*1
0.5 - 0.0
E1-10
Minimum Output
Voltage
0.0 - 255.0
*2
0.1 V 9.0
*1
9.0
*1
3.0 - 0.0
E1-14
Middle Out Freq
Volt Select 1
0.0 - 255.0
*2
0.1 V 15.0
*1
15.0
*1
14.4 - 0.0
E1-15
Minimum Out
Freq Volt Select
1
0.0 - 255.0 0.1 V 9.0
*1
9.0
*1
3.0 - 0.0
E1-16
Middle Out Freq
Volt Select 2
0.0 - 255.0 0.1 V 15.0
*1
15.0
*1
14.4 - 0.0
E1-17
Minimum Out
Freq Volt Select
2
0.0 - 255.0
*2
0.1 V 9.0
*1
9.0
*1
3.0 - 0.0
E1-18
Middle Out Freq
Volt Select 3
0.0 - 255.0 0.1 V 15.0
*1
15.0
*1
14.4 - 0.0
E1-19
Minimum Out
Freq Volt Select
3
0.0 - 255.0 0.1 V 9.0
*1
9.0
*1
3.0 - 0.0
F1-01
Encoder 1 Pulse
Count (PPR)
0 - 60000 1 ppr 600 600 600 600 600
F1-05
Encoder 1
Rotation
Selection
0 - 1 1 0 0 0 0 0
F1-09
Overspeed
Detection Delay
Time
0.0 - 2.0 0.1 s - 1.0 - 0.0 0.1
H4-20
Analog Power
Monitor 100%
Level
0.00 - 650.00 0.01
Default value of
E2-11
Default value of
E2-11
Determined by
E2-11
Determined by
E2-11
Determined by
E2-11
L1-01
Motor Overload
(oL1) Protection
0 - 4 1 1 1 1 1 1
L3-05
Stall Prevention
during RUN
0 - 3 1 1 1 - - -
L3-20
DC Bus Voltage
Adjustment Gain
0.00 - 5.00 0.01 1.00 1.00 0.30 0.30 0.30
L3-21
OVSuppression
Accel/Decel P
Gain
0.10 - 10.00 0.01 1.00 1.00 1.00 1.00 1.00
L3-36
Current
Suppression
Gain@Accel
0.0 - 100.0 0.1 10.0 10.0 20.0 - -
L4-01
Speed Agree
Detection Level
0.0 - 400.0 0.1 0.0 Hz 0.0 Hz 0.0 Hz 0.0 Hz 0.0 Hz
L4-02
Speed Agree
Detection Width
0.0 - 20.0 0.1 2.0 Hz 2.0 Hz 2.0 Hz 2.0 Hz 2.0 Hz
L4-03
Speed Agree
Detection Level
(+/-)
-400.0 - +400.0 0.1 0.0 Hz 0.0 Hz 0.0 Hz 0.0 Hz 0.0 Hz
L4-04
Speed Agree
Detection Width
(+/-)
0.0 - 20.0 0.1 2.0 Hz 2.0 Hz 2.0 Hz 2.0 Hz 2.0 Hz
L8-38
Carrier
Frequency
Reduction
0 - 2 1 2 2 2 2 0
L8-40
Carrier Freq
Reduction Off-
Delay
0.00 - 2.00 0.01 s 0.50 0.50 0.50 0.50 0.50
