YASKAWA CR700 Technical Manual

11.6 E: Motor Parameters
650 YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual
■ E7-12: Motor 3 Mid Point B Voltage
No.
(Hex.)
Name Description
Default
(Range)
E7-12
(1B69)
Expert
Motor 3 Mid Point B
Voltage
Sets the mid point B voltage used for motor 3.
0.0 V
(200 V Class: 0.0 to 255.0
V, 400 V Class: 0.0 to 510.0
V)
■ E7-13: Motor 3 Base Voltage
No.
(Hex.)
Name Description
Default
(Range)
E7-13
(1B6A)
Expert
Motor 3 Base Voltage
Sets the base voltage used for motor 3.
0.0 V
(200 V Class: 0.0 to 255.0
V, 400 V Class: 0.0 to 510.0
V)
■ E7-21: Motor 3 Rated Current
No.
(Hex.)
Name Description
Default
(Range)
E7-21
(1B72)
Motor 3 Rated Current
Sets the motor rated current for motor 3 in amperes.
Determined by o2-04
(10% to 200% of the drive
rated current)
■ E7-24: Motor 3 Motor Poles
No.
(Hex.)
Name Description
Default
(Range)
E7-24
(1B75)
Motor 3 Motor Poles
Sets the number of poles for motor 3.
4
(2 - 48)
■ E7-25: Motor 3 Line-to-Line Resistance
No.
(Hex.)
Name Description
Default
(Range)
E7-25
(1B76)
Motor 3 Line-to-Line
Resistance
Sets the line-to-line resistance for the motor 3 stator windings.
Determined by o2-04
(0.000 - 65.000 Ω)
■ E7-31: Motor 3 Rated Power
No.
(Hex.)
Name Description
Default
(Range)
E7-31
(1B7C)
Motor 3 Rated Power
Sets the motor 3 rated power in 0.01 kW. (1 HP = 0.746 kW) (1 HP = 0.746 kW)
Determined by o2-04
(0.00 - 650.00 kW)
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
