10.16 U: Monitors
540 YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual
No.
(Hex.)
Name Description MFAO Signal Level
U1-11
(004A)
Output Terminal Status
Shows the status of the multi-function output terminal with 1 (ON) and 0 (OFF).
For example, U1-11 = 00000011 is shown when terminals M1 and M3 are ON.
bit 0 : Terminals M1-M2
bit 1 : Terminals M3-M4
bit 2 : Terminals M5-M6
bit 3 : Terminals P1-C1
bit 4 : Terminals P2-C2
bit 5 : Not used (normal value of 0).
bit 6 : Not used (normal value of 0).
bit 7 : Fault relay MA/MB-MC
No signal output available
U1-12
(004B)
Drive Status
Shows drive status where 1 = ON and 0 = OFF.
For example, U1-12 shows “00000101” during run with the Reverse Run command.
bit0 : During Run
bit1 : During zero-speed
bit2 : During reverse
bit3 : During fault reset signal input
bit4 : During speed agreement
bit5 : Drive ready
bit6 : During minor fault detection
bit7 : During fault detection
No signal output available
U1-13
(004E)
Terminal A1 Level
Shows the signal level of terminal A1.
Unit: 0.1%
10 V = 100% (0 V to +10
V)
U1-14
(004F)
Terminal A2 Level
Shows the signal level of terminal A2.
Unit: 0.1%
10 V = 100% (0 V to +10
V)
U1-15
(0050)
Terminal A3 Level
Shows the signal level of terminal A3.
Unit: 0.1%
10 V = 100% (-10 V to +10
V)
U1-16
(0053)
SFS Output Frequency
Shows the output frequency after soft start. Shows the frequency with acceleration and
deceleration times and S-curves. Parameter o1-03 [Keypad Display Unit Selection] sets the
display units.
Unit: 0.01 Hz
10 V = Maximum
frequency (0 V to +10 V)
U1-17
(0058)
DI-A3 Input Status
Shows the reference value input from DI-A3 option.
Shows the input signal for DI-A3 in hexadecimal as set in F3-01 [Digital Input Function
Selection].
3FFFF: Set (1 bit) + Sign (1 bit) + 16 bit
No signal output available
U1-18
(0061)
oPE Fault Parameter
Shows the parameter number that caused the oPE02 [Parameter Range Setting Error] or oPE08
[Parameter Selection Error].
No signal output available
U1-19
(0066)
MEMOBUS/Modbus Error
Code
Shows the contents of the MEMOBUS/Modbus communication error where 1 = “error” and 0 =
“no error”.
For example, U1-19 shows “00000001” when there is a CRC error.
bit0 : CRC Error
bit1 : Data Length Error
bit2 : Not used (normal value of 0).
bit3 : Parity Error
bit4 : Overrun Error
bit5 : Framing Error
bit6 : Timed Out
bit7 : Not used (normal value of 0).
No signal output available
U1-21
(0077)
AI-A3 Term V1 Level
Shows the analog reference of terminal V1 on analog input option card AI-A3.
Unit: 0.1%
10 V = 100% (-10 V to +10
V)
U1-22
(072A)
AI-A3 Term V2 Level
Shows the analog reference of terminal V2 on analog input option card AI-A3.
Unit: 0.1%
10 V = 100% (-10 V to +10
V)
U1-23
(072B)
AI-A3 Term V3 Level
Shows the analog reference of terminal V3 on analog input option card AI-A3.
Unit: 0.1%
10 V = 100% (-10 V to +10
V)
U1-25
(004D)
SoftwareNumber Flash
Shows the FLASH ID.
No signal output available
