Parameter Details
11
11.7 F: Options
YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual 681
■ F7-13: Address Mode at Startup
No.
(Hex.)
Name Description
Default
(Range)
F7-13
(03F1)
Address Mode at Startup
Sets the method to set option card IP addresses.
2
(0 - 2)
0 : Static
1 : BOOTP
2 : DHCP
Note:
• The following setting values are available when using the PROFINET communication option card (SI-EP3).
–0: Static
–2: DCP
• When F7-13 = 0, set parameters F7-01 to F7-12 [IP Address 1 to Gateway Address 4] to set the IP Address. Be sure to set a different
IP address for each drive on the network.
■ F7-14: Duplex Mode Selection
No.
(Hex.)
Name Description
Default
(Range)
F7-14
(03F2)
Duplex Mode Selection
Sets the duplex mode setting method.
1
(0 - 8)
0 : Half/Half
1 : Auto/Auto
2 : Full/Full
3 : Half/Auto
Port 1 is set to “Half” and port 2 is set to “Auto”.
4 : Half/Full
Port 1 is set to “Half” and port 2 is set to “Full”.
5 : Auto/Half
Port 1 is set to “Auto” and port 2 is set to “Half”.
6 : Auto/Full
Port 1 is set to “Auto” and port 2 is set to “Full”.
7 : Full/Half
Port 1 is set to “Full” and port 2 is set to “Half”.
8 : Full/Auto
Port 1 is set to “Full” and port 2 is set to “Auto”.
■ F7-15: Communication Speed Selection
No.
(Hex.)
Name Description
Default
(Range)
F7-15
(03F3)
Communication Speed
Selection
Sets the communications speed.
10
(10, 100 - 102)
10 : 10/10 Mbps
100 : 100/100 Mbps
101 : 10/100 Mbps
102 : 100/10 Mbps
Note:
Set this parameter when F7-14 = 0 or 2 [Duplex Mode Selection = Half/Half or Full/Full].
■ F7-16: Timeout Value
No.
(Hex.)
Name Description
Default
(Range)
F7-16
(03F4)
Timeout Value
Sets the detection time for a communications timeout.
0.0 s
(0.0 - 30.0 s)
