YASKAWA CR700

11.7 F: Options
684 YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual
■ F7-68: PZD9 Write
No.
(Hex.)
Name Description
Default
(Range)
F7-68
(0788)
PZD9 Write
When you use a Profibus option, sets the MEMOBUS/Modbus address for PZD9 (PPO output). A
value of 0, 1, or 2 will disable the PZD9 (PPO output) write operation to the MEMOBUS/Modbus
register.
0
■ F7-69: PZD10 Write
No.
(Hex.)
Name Description
Default
(Range)
F7-69
(0789)
PZD10 Write
When you use a Profibus option, sets the MEMOBUS/Modbus address for PZD10 (PPO output).
A value of 0, 1, or 2 will disable the PZD10 (PPO output) write operation to the MEMOBUS/
Modbus register.
0
■ F7-70: PZD1 Read (Status Word)
No.
(Hex.)
Name Description
Default
(Range)
F7-70
(078A)
PZD1 Read (Status Word)
When you use a Profibus option, sets the MEMOBUS/Modbus address for PZD1 (PPO input).
PZD1 (PPO input) functions as the ZSW when F7-70 = 0.
0
■ F7-71: PZD2 Read (Output Frequency)
No.
(Hex.)
Name Description
Default
(Range)
F7-71
(078B)
PZD2 Read (Output
Frequency)
When you use a Profibus option, sets the MEMOBUS/Modbus address for PZD2 (PPO input).
PZD2 (PPO input) functions as the HIW when F7-71 = 0.
0
■ F7-72: PZD3 Read
No.
(Hex.)
Name Description
Default
(Range)
F7-72
(078C)
PZD3 Read
When you use a Profibus option, sets the MEMOBUS/Modbus address for PZD3 (PPO input). A
value of 0 will disable the PZD3 (PPO input) load operation from the MEMOBUS/Modbus
register.
0
■ F7-73: PZD4 Read
No.
(Hex.)
Name Description
Default
(Range)
F7-73
(078D)
PZD4 Read
When you use a Profibus option, sets the MEMOBUS/Modbus address for PZD4 (PPO input). A
value of 0 will disable the PZD4 (PPO input) load operation from the MEMOBUS/Modbus
register.
0
■ F7-74: PZD5 Read
No.
(Hex.)
Name Description
Default
(Range)
F7-74
(078E)
PZD5 Read
When you use a Profibus option, sets the MEMOBUS/Modbus address for PZD5 (PPO input). A
value of 0 will disable the PZD5 (PPO input) load operation from the MEMOBUS/Modbus
register.
0
■ F7-75: PZD6 Read
No.
(Hex.)
Name Description
Default
(Range)
F7-75
(078F)
PZD6 Read
When you use a Profibus option, sets the MEMOBUS/Modbus address for PZD6 (PPO input). A
value of 0 will disable the PZD6 (PPO input) load operation from the MEMOBUS/Modbus
register.
0
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
