11.8 H: Terminal Functions
700 YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual
ON : Selects motor 3
OFF : Select motor 1 or motor 2 (Select the terminal assigned H1-xx = 16 [Motor 2 Selection])
Note:
• Set H1-xx = 16, when setting H1-xx = 39. If H1-xx = 39 is set while H1-xx = 16 is not set, oPE03 [Multi-Function Input Setting Err]
is detected.
• Refer to
Motor Switch Function on page 216 for details.
■ 3A: Micro Speed Gain1
Setting Value Function Description
3A Micro Speed Gain1
Multiplies the gain set in S2-16 [Micro Speed Gain1] by the final step of frequency reference when the terminal is ON.
■ 3B: Micro Speed Gain2
Setting Value Function Description
3B Micro Speed Gain2
Multiplies the gain set in S2-17 [Micro Speed Gain2] by the final step of frequency reference when the terminal is ON.
■ 40: Forward RUN (2-Wire)
Setting Value Function Description
40 Forward RUN (2-Wire)
Input the Forward Run command for 2-wire sequence 1. Use it paired with the Reverse Run Command (2-Wire Seq) [H1-xx =
41].
ON : Forward Run
OFF : Run Stop
Note:
• When the both Forward run command and Reverse run command terminals have been turned ON, the drive detects EF [FWD/REV Run
Command Input Error] (minor fault), and the motor ramps to stop.
• The Forward run/Reverse run command is set to terminals S1 and S2 when the drive is initialized using a 2-wire sequence.
■ 41: Reverse RUN (2-Wire)
Setting Value Function Description
41 Reverse RUN (2-Wire)
Input the Reverse run command for 2-wire sequence 1. Use it paired with the Forward Run Command (2-Wire Seq) [H1-xx =
40].
ON : Reverse Run
OFF : Run Stop
Note:
• When the both Forward run command and Reverse run command terminals have been turned ON, the drive detects EF [FWD/REV Run
Command Input Error] (minor fault), and the motor ramps to stop.
• The Reverse run command is set to terminal S2 when the drive is initialized using a 2-wire sequence.
■ 44: Add Offset Frequency 1 (d7-01)
Setting Value Function Description
44 Add Offset Frequency 1
(d7-01)
Sets the function to add the offset frequency set in d7-01 [Offset Frequency 1] to the frequency reference when the terminal
activates.
Note:
Refer to
d7: Offset Frequency on page 632 for more information.
■ 45: Add Offset Frequency 2 (d7-02)
Setting Value Function Description
45 Add Offset Frequency 2
(d7-02)
Sets the function to add the offset frequency set in d7-02 [Offset Frequency 2] to the frequency reference when the terminal
activates.
Note:
Refer to
d7: Offset Frequency on page 632 for more information.
