11.8 H: Terminal Functions
YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual 707
■ H2-26: Comparator 2 Monitor Selection
No.
(Hex.)
Name Description
Default
(Range)
H2-26
(1546)
Comparator 2 Monitor
Selection
Sets the monitor number for comparator 2. Set the x-xx part of the Ux-xx [Monitor]. For example,
set H2-26 = 103 to monitor U1-03 [Output Current].
103
(000 - 999)
Note:
• The configurable monitor changes when the control method changes.
• When you use the terminal in through mode, set this parameter to 000 or 031. You can set the terminal output level from the PLC
through MEMOBUS/Modbus communications or the communication option.
• For information on the comparator function, refer to
66: Comparator1 on page 722 and 67: Comparator2 on page 722.
■ H2-27: Comparator 2 Lower Limit
No.
(Hex.)
Name Description
Default
(Range)
H2-27
(1547)
Comparator 2 Lower Limit
Sets the lower limit detection level for comparator 2 as a percentage of the full scale analog output
for the monitor selected in H2-26 [Comparator 2 Monitor Selection].
0.0%
(0.0 - 300.0%)
Note:
For information on the comparator function, refer to
66: Comparator1 on page 722 and 67: Comparator2 on page 722.
■ H2-28: Comparator 2 Upper Limit
No.
(Hex.)
Name Description
Default
(Range)
H2-28
(1548)
Comparator 2 Upper Limit
Sets the upper limit detection level for comparator 2 as a percentage of the full scale analog output
for the monitor selected in H2-26 [Comparator 2 Monitor Selection].
0.0%
(0.0 - 300.0%)
Note:
For information on the comparator function, refer to
66: Comparator1 on page 722 and 67: Comparator2 on page 722.
■ H2-29: Comparator 2 Hysteresis
No.
(Hex.)
Name Description
Default
(Range)
H2-29
(1549)
Comparator 2 Hysteresis
Sets the hysteresis level for comparator 2 as a percentage of the full scale analog output for the
monitor selected in H2-26 [Comparator 2 Monitor Selection].
0.0%
(0.0 - 10.0%)
Note:
For information on the comparator function, refer to
66: Comparator1 on page 722 and 67: Comparator2 on page 722.
■ H2-30: Comparator 2 On-Delay Time
No.
(Hex.)
Name Description
Default
(Range)
H2-30
(154A)
Comparator 2 On-Delay
Time
Sets the on-delay time for comparator 2.
0.0 s
(0.0 - 600.0 s)
Note:
Refer to H2-xx = 66 and 67 [Multi-Function Digital Out Function Select = Comparator1 and Comparator 2] for more information on
the comparator function.
■ H2-31: Comparator 2 Off-Delay Time
No.
(Hex.)
Name Description
Default
(Range)
H2-31
(154B)
Comparator 2 Off-Delay
Time
Sets the off-delay time for comparator 2.
0.0 s
(0.0 - 600.0 s)
Note:
Refer to H2-xx = 66 and 67 [Multi-Function Digital Out Function Select = Comparator1 and Comparator 2] for more information on
the comparator function.
