YASKAWA CR700 Technical Manual

11.8 H: Terminal Functions
710 YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual
■ H2-62: Terminal M1-M2 Delay Time
No.
(Hex.)
Name Description
Default
(Range)
H2-62
(1B48)
Expert
Terminal M1-M2 Delay
Time
Sets the minimum on time used to output the logical calculation results from terminal M1-M2.
0.1 s
(0.0 - 25.0 s)
■ H2-63: Term M3-M4 Secondary Function
No.
(Hex.)
Name Description
Default
(Range)
H2-63
(1B49)
Expert
Terminal P1 Secondary
Function
Sets the second function for terminal M3-M4. Outputs the logical calculation results of the
terminals assigned to functions by H2-02 [Term P1 Function Selection].
F
(0 - FF)
■ H2-64: Terminal M3-M4 Logical Operation
No.
(Hex.)
Name Description
Default
(Range)
H2-64
(1B4A)
Expert
Terminal P1 Logical
Operation
Selects the logical operation for the two functions selected by H2-02 [Term M3-M4 Function
Selection] and H2-63 [Term M3-M4 Secondary Function].
0
(0 - 8)
Note:
Refer to
Output of Logical Operation Results of MFDO on page 703 for more information about the relationship between parameter
settings and logical operations.
■ H2-65: Terminal M3-M4 Delay Time
No.
(Hex.)
Name Description
Default
(Range)
H2-65
(1B4B)
Expert
Terminal M3-M4 Delay
Time
Sets the minimum on time used to output the logical calculation results from terminal M3-M4.
0.1 s
(0.0 - 25.0 s)
■ H2-66: Term M5-M6 Secondary Function
No.
(Hex.)
Name Description
Default
(Range)
H2-66
(1B4C)
Expert
Term M5-M6 Secondary
Function
Sets the second function for terminal M5-M6. Outputs the logical calculation results of the
terminals assigned to functions by H2-03 [Term P1-C1 Function Selection].
F
(0 - FF)
■ H2-67: Terminal M5-M6 Logical Operation
No.
(Hex.)
Name Description
Default
(Range)
H2-67
(1B4D)
Expert
Terminal M5-M6 Logical
Operation
Sets the logical operation for the two functions selected by H2-03 [Terminal M5-M6 Function
Select] and H2-66 [Term M5-M6 Secondary Function].
0
(0 - 8)
Note:
Refer to
Output of Logical Operation Results of MFDO on page 703 for more information about the relationship between parameter
settings and logical operations.
■ H2-68: Terminal M5-M6 Delay Time
No.
(Hex.)
Name Description
Default
(Range)
H2-68
(1B4E)
Expert
Terminal P2 Minimum ON
Time
Sets the minimum on time used to output the logical calculation results from terminal M5-M6.
0.1 s
(0.0 - 25.0 s)
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
V/f
CL-V/f
OLV
CLV
AOLV
