11.8 H: Terminal Functions
742 YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual
■ H7-01: Virtual Multi-Function Input 1
No.
(Hex.)
Name Description
Default
(Range)
H7-01
(1185)
Expert
Virtual Multi-Function
Input 1
Sets the function that enters the virtual input set in H7-10 [Virtual Multi-Function Output 1].
F
(0 - 1FF)
■ H7-02: Virtual Multi-Function Input 2
No.
(Hex.)
Name Description
Default
(Range)
H7-02
(1186)
Expert
Virtual Multi-Function
Input 2
Sets the function that enters the virtual input set in H7-12 [Virtual Multi-Function Output 2].
F
(0 - 1FF)
■ H7-03: Virtual Multi-Function Input 3
No.
(Hex.)
Name Description
Default
(Range)
H7-03
(1187)
Expert
Virtual Multi-Function
Input 3
Sets the function that enters the virtual input set in H7-14 [Virtual Multi-Function Output 3].
F
(0 - 1FF)
■ H7-04: Virtual Multi-Function Input 4
No.
(Hex.)
Name Description
Default
(Range)
H7-04
(1188)
Expert
Virtual Multi-Function
Input 4
Sets the function that enters the virtual input set in H7-16 [Virtual Multi-Function Output 4].
F
(0 - 1FF)
■ H7-10: Virtual Multi-Function Output 1
No.
(Hex.)
Name Description
Default
(Range)
H7-10
(11A4)
Expert
Virtual Multi-Function
Output 1
Sets the function for virtual digital output 1.
F
(0 - 1FF)
■ H7-11: Virtual Output 1 Delay Time
No.
(Hex.)
Name Description
Default
(Range)
H7-11
(11A5)
Expert
Virtual Output 1 Delay
Time
Sets the minimum ON time for virtual digital output 1.
0.1 s
(0.0 - 25.0 s)
■ H7-12: Virtual Multi-Function Output 2
No.
(Hex.)
Name Description
Default
(Range)
H7-12
(11A6)
Expert
Virtual Multi-Function
Output 2
Sets the function for virtual digital output 2.
F
(0 - 1FF)
■ H7-13: Virtual Output 2 Delay Time
No.
(Hex.)
Name Description
Default
(Range)
H7-13
(11A7)
Expert
Virtual Output 2 Delay
Time
Sets the minimum ON time for virtual digital output 2.
0.1 s
(0.0 - 25.0 s)
