YASKAWA NX100 Instructions

8.12 Instruction Level Setting
8-82
8.12.2 Setting the Instruction Set Level
Operation Explanation
1 Select {SETUP} under the
main menu.
2 Select {TEACHIG COND}. The TEACHING CONDITION window appears.
3 Select “LANGUAGE LEVEL”. The selection list appears.
4 Select desired language level. Language level is set.
Short CutMain Menu
TEACHING CONDITION
DATA EDIT DISPLAY UTILITY
RECT/ CYLINDRICAL
LANGUAGE LEVEL
INSTRUCTION INPUT LEARNING
MOVE INSTRUCTION SET
STEP ONLY CHANGING
Turn on servo power
RECT
SUBSET
VALID
STEP
PROHIBIT
Short CutMain Menu
TEACHING CONDITION
DATA EDIT DISPLAY UTILITY
RECT/ CYLINDRICAL
LANGUAGE LEVEL
INSTRUCTION INPUT LEARNING
MOVE INSTRUCTION SET
STEP ONLY CHANGING
Turn on servo power
RECT
SUBSET
VALID
STEP
PROHIBIT
SUBSET
STANDARD
EXPANDED
Short CutMain Menu
TEACHING CONDITION
DATA EDIT DISPLAY UTILITY
RECT/ CYLINDRICAL
LANGUAGE LEVEL
INSTRUCTION INPUT LEARNING
MOVE INSTRUCTION SET
STEP ONLY CHANGING
Turn on servo power
RECT
STANDARD
VALID
STEP
PROHIBIT
