4.3 Connection Methods
4-11
4.3.3 Connecting the Programming Pendant
Connect the programming pendant cable to the connector on the door lower right side of the
controller cabinet.
Connecting the Programming Pendant
The manipulator, NX100, and the programming pendant connections are now complete.
Alignment mark
