12.2 Function List
12-3
12.2 Function List
External Dimensions
Small capacity HP3, HP6, EA1400N, HP20, EA1900N
500(W)
× 1200(H) × 500(D) mm
Medium and
Large capacity
UP20MN, UP50N, ES165N, HP165, ES200N, ES165RN, ES200RN
600(W)
× 1200(H) × 550(D) mm
Programming
Pendant
Operation
Coordinate System Joint, Rectangular/Cylindrical, Tool, User Coordinates
Modification of
Teaching Points
Adding, Deleting, Correcting (Robot axes and external axes
respectively can be corrected.)
Inching Operation Possible
Path Confirmation Forward/Reverse step, Continuous feeding
Speed Adjustment Fine adjustment possible during operating or pausing
Timer Setting Possible every 0.01 s
Short-cut Function Direct-open function
Interface CF (Compact Flash) card slot (At Programming Pendant)
RS232C (At Control Circuit Board)
LAN (100 BASE-TX/10BASE-T) (At Control Circuit Board)
(Option)
Application Arc welding, Spot welding, Handling, General, Others
Safety
Feature
Essential Measures JIS (Japanese Industrial Standard)
Running Speed
Limit
User definable
Enable Switch 3 position type. Servo power can be turned on at the middle
position only. (Located on programming pendant)
Collision proof
Frames
S-axis frame (doughnut-sector), Cubic frame (user coordi-
nate)
Self-Diagnosis Classifies error and two types of alarms (major and minor)
and displays the data
User Alarm Display Possible to display alarm messages for peripheral device
Machine Lock Test-run of peripheral devices without robot motion
Door Interlock A door can be opened only when a circuit breaker is OFF.

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
