9.3 Automatic Backup Function
9-13
Window Settings
RS parameter can restrict the settings of some items in the automatic backup window.
When setting the bit of RS096 parameter shown below to "1", the corresponding items are
restricted. The restricted items are indicated with "INVALID" in the display and inputting/mod-
ification to the item becomes impossible. Also, the automatic backup does not function with
the restricted items.
5 (Continued from the previous
page.)
J. DURING ALARM OCCURENCE
Set the backup function to be valid or invalid when an alarm is
occurred.
Each time [SELECT] is pressed, "INVALID" and "VALID" are
displayed alternately.
K. STORED FILE SETTING
Set the number of files to be stored by the automatic
backup function. The number mentioned on the right
side of this item with "(Max)" indication is the maximum
number of files that can be stored in the CompactFlash
inserted when this window is displayed.
The settings range from 1 to (Max). When this setting value
is changed, the backup file sort starts.
L. BACKUP FILES
Indicates the existence of the files or the number of backup
files stored in the CompactFlash inserted when this window
is displayed.
M. LATEST BACKUP FILE
Indicates the date of the latest file in the CompactFlash
inserted when this window is displayed.
N. SORT FILE
When the setting of maximum number of stored files is
changed, the file sort of the backup files in the CompactFlash
is executed. With this operation, the file sort can be performed
without changing the maximum number of stored files.
6 Set the desired item, and
press [ENTER].
Operation Explanation
RESERVE TIME BACKUP
MODE CHANGE BACKUP
STARTUP BACKUP
RETRY CYCLE
DURING ALARM BACKUP
SPECIFIC INPUT BACKUP
D5 D4 D3 D2 D1 D0D6D7

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
