8.15 Numeric Key Customize Function

8-88

 Key Allocation (SIM)

With key allocation (SIM), the manipulator operates according to the allocated function when

the [INTERLOCK] and the numeric key are pressed at the same time. The allocatable func-

tions are listed below.

Function Description

Alternate output

allocation

Turns ON/OFF the specified user output signal when [INTERLOCK] and

the allocated Numeric key are pressed at the same time.

Momentary output

allocation

Turns ON the specified user output signal user when [INTERLOCK] and

the allocated user key are pressed at the same time.

Pulse output

allocation

Turns ON the specified user output signal only for the specified period

when [INTERLOCK] and the allocated Numeric key are pressed at the

same time.

Group output

allocation

(4-bit/8-bit)

Sends the specified output to the specified general group output signals

when [INTERLOCK] and the allocated Numeric key are pressed at the

same time.

Analog output

allocation

Sends the specified voltage to the specified output port when [INTER-

LOCK] and the allocated Numeric key are pressed at the same time.

Analog incremental

output allocation

Sends the voltage increased by the specified value to the specified out-

put port when [INTERLOCK] and the allocated Numeric key are pressed

at the same time.

In a system for multiple applications, a numeric key can be allocated for each application.

SUPPLE

-MENT
