8.16 Changing the Output Status
8-101
8.16 Changing the Output Status
The status of external output signals can be changed from the programming pendant by using
either of the following two methods.
• On the user output status window
• On the RELAY ON window
The method that uses the RELAY ON window, which is described here, simplifies the opera-
tion for changing the status of signals that are used frequently.
A maximum of 32 output signals can be shown on the RELAY ON window and they must
be set in advance to parameters S4C181 to S4C212. If they are not set, the sub menu in
the RELAY ON window will not be displayed.
Operation Explanation
1 Select {IN/OUT} under the
main menu.
2 Select {RELAY ON}. The RELAY ON window appears.
3 Select the desired signal to
change the output status.
Select the status ( or ) of the desired signal.
4 Press [INTERLOCK]
+[SELECT].
The output status is changed. (
: status ON; : status OFF.)
It is also possible to turn the relevant external output signal on only for the duration that
[INTERLOCK]+[SELECT] are pressed. This selection is made in advance by setting the
parameters (S4C213 to 244) to “1”.
NOTE
RELAY ON
DATA EDIT DISPLAY UTILITY
OUTPUT NO. STATUS NAME
OUT#0010
OUT#0012
OUT#0014
OUT#0016
OUT#0018
OUT#0015
OUT#0017
OUT#0019
[
[
[
[
[
[
[
[
]
]
]
]
]
]
]
]
RELAY ON
DATA EDIT DISPLAY UTILITY
OUTPUT NO. STATUS NAME
OUT#0010
OUT#0012
OUT#0014
OUT#0016
OUT#0018
OUT#0015
OUT#0017
OUT#0019
[
[
[
[
[
[
[
[
]
]
]
]
]
]
]
]
SUPPLE
-MENT
