13.5 SERVOPACK
13-34
13.5 SERVOPACK
A SERVOPACK consists of a converter and a PWM amplifier of which there are two types.
One type is the SERVOPACK with a combined converter and a PWM amplifier and the other
type is one where both units are separate. (Refer to attached table “SERVOPACK
Configuration”).
13.5.1 Description of Each Unit
 Converter
This exchanges the power supply (3-phase : AC200/220V) supplied by the contactor unit for
DC power supply and supplies the power to PWM amplifiers for each axis.
 PWM Amplifier
This exchanges the DC power supply supplied by a converter for a 3-phase motor power
source and outputs to each servo motor.
13.5.2 SERVOPACK Configuration
Configuration device
HP3 HP6, EA1400N
Model Model
SERVOPACK SGDR-EA1400NY26 SGDR-EA1400N
Converter SGDR-COA040A01B SGDR-COA040A01B
PWM
Amplifier
S SGDR-SDA060A01B SGDR-SDA140A01BY22
L SGDR-SDA060A01B SGDR-SDA140A01BY22
U SGDR-SDA060A01B SGDR-SDA140A01BY22
R SGDR-SDA060A01B SGDR-SDA060A01B
B SGDR-SDA060A01B SGDR-SDA060A01B
T SGDR-SDA060A01B SGDR-SDA060A01B

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
