9.1 System Backup with NX100

9-1

9 System Backup

For the NX100, the system data can be collectively backed up in advance so that the data can

be immediately loaded and restored in case of an unexpected trouble such as data loss.

9.1 System Backup with NX100

For the NX100, four types of collective backup are available: CMOS.BIN, CMOSBK.BIN, ALC-

MSxx.HEX, and CMOSxx.HEX.

9.1.1 Function Types of Data

 CMOS.BIN

For the normal backup, use this data.

Save: Perform in the maintenance mode (the editing mode or higher.)

Load: Perform in the maintenance mode (the management mode.)

As for the load/save procedures, refer to " 9.2 Backup by CMOS.BIN ".

Target Area: All areas of the internally stored data. (Note that the monitoring time is not

loaded.)

 CMOSBK.BIN

This data is used in the automatic backup function.

Save: Saves with the preset conditions in the normal mode.

Load: Perform the system restore in the maintenance mode (the management mode.)

For details, refer to " Fig. 9.3 Automatic Backup Function ".

Target Area: All areas of the internally stored data. (Note that the monitoring time is not

loaded.)

 CMOSxx.HEX

This data is loaded/saved in the FD/CF menu in the normal mode.

Save: Perform in the normal mode (the editing mode or higher.)

Load: Perform in the normal mode (the management mode.)

For details, refer to "NX100 OPERATOR’S MANUAL."

Target Area: A set of data which can be individually loaded/saved in the FD/CF menu (e.g.

"Job File," "Data File," "Parameter Batch," "System Data," and "I/O Data.")

Since the setting information of robot etc. are not included in this set of data,

the system cannot be completely restored.

 ALCMSxx.HEX

This data is for the manufacturer only. Users can save but cannot load this data.
