9.1 System Backup with NX100
9-2
9.1.2 Device
For the backup of the NX100 system, the CompactFlash can be used.
The following tables show the recommended CompactFlash.
<Currently Recommended CompactFlash>
<Previously Recommended CompactFlash>
In order to save the batch data, the following free space per file is needed in the Compact-
Flash.
JZNC-NIF01-1: (The number of stored file + 1) x 7.5 MByte
JZNC-NIF01-2: (The number of stored file + 1) x 11.0 MByte
Note that the free space for one working file is needed in addition to the free space for the
stored files when using the automatic backup function.
Also, it is recommended to store the backup data in two or more CompactFlash cards to mini-
mize problems if the CompactFlash is damaged.
No. Manufacturer Model Remarks
1
Hagiwara Sys-Com MCF10P-128MS
(A00A II -YE
(128MB)
2
Hagiwara Sys-Com MCF10P-256MS-YE2 (256MB)
3
Hagiwara Sys-Com MCF10P-512MS (512MB)
4
Hagiwara Sys-Com MCF10P-A01GS (1GB)
5
Hagiwara Sys-Com MCF10P-A02GS (2GB)
No. Manufacturer Model Remarks
1
Hagiwara Sys-Com CFI-128MDG (128MB)
2
Hagiwara Sys-Com CFI-256MDG (256MB)
3
Hagiwara Sys-Com CFC-064MBA
(HOOAA)
(64MB)
4
Hagiwara Sys-Com CFI-064MBA
(HOOAA)
(64MB)
5
SanDisk SDCFBI-64-EXPP-80 (64MB)
To Next Page
