8.15 Numeric Key Customize Function
8-100
8.15.5 Execution of Allocation
 Executing the Instruction/Output Control Allocation
 Executing the Job Call Allocation
 Executing the Window Allocation
 Executing the I/O Control Allocation
Alternate output allocation, momentary output allocation, pulse output allocation, group output
allocation (4-bit/8-bit), analog output allocation, analog incremental output allocation are exe-
cuted by the following operation.
Operation Explanation
1 Press the key allocated for
instruction allocation or output
control allocation.
The allocated instruction is displayed in the input buffer line.
2 Press [INSERT] and [ENTER]. The instruction displayed in the input buffer line is registered.
Operation Explanation
1 Press the key allocated for the
job call allocation.
The CALL instruction is displayed in the input buffer line.
2 Press [INSERT] and [ENTER]. The CALL instruction shown in the input buffer line is registered.
Operation Explanation
1 Press the key allocated for the
window allocation.
The allocated window appears.
Operation Explanation
1 Press [INTERLOCK] and the
key allocated for I/O control
allocation at the same time.
Allocated functions are executed.
=> WAIT IN#(1)=ON
=> CALL JOB:ARCON
