YASKAWA NX100 Instructions

9.3 Automatic Backup Function
9-18
5 Select {CompactFlash}. The CompactFlash display appears.
Move the cursor to SYSTEM RESTORE.
6 Select {SYSTEM RESTORE}
in the CompactFlash display.
The Backup File list display appears.
7 Select the file to be loaded. The dialog box appears for the NIF/NCP01 board replacement
confirmation.
Select {YES} if the NIF/NCP01 board has been replaced, or
select {NO} if it has not been replaced. Selecting {YES} initial-
izes the system monitoring time.
Selecting {NO} continues the counting of the current system’s
monitoring time.
Operation Explanation

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
