13.6 User I/O Signal Assignment

13-63

*1 This signal is not output during operation.

*2 The work home position cube and Cube 32 are same.

*3 This signal can be allocated to any user I/O signal at the I/O allocation display in oper-

ation condition.

*4 This signal can be select “USE” or “NOT USE” by pseudo input signal ”8202x”. If “NOT

USE” is selected, this signal can be used as the user I/O signal described in parenthe-

ses.

30057 TIP REPLACE REQUEST

This signal is output when the stored number

of welding reaches the number of welding set

for the tip replacement.

System Output List NIO01 (Spot Welding)

Logical

Number

Output Name / Function

Logical

Number

Output Name / Function

Timer Cooling Water Error Validating (or IN09)

Gun Cooling Water Error Validating (or IN10)

Transthermo Error Validating (or IN11)

Low Air Pressure Validating (or IN12)

Weld ON/OFF Validating (or OUT09)

7 6 5 4 3 2 1 0

0 0 0 1 1 1 1 1

Pseudo Input

Signal 8202x
