ZXR10 GER (V2.6.03) General Excellent Router User Manual Volume-I
122 Confidential and Proprietary Information of ZTE CORPORATION
ZXR10(config-if)#ip forwarding-mode vlan-switch
ZXR10(config)#vlan-
f
orwarding ingress fei
_
1/1 10
egress fei_1/3 20
ZXR10(config)#vlan-
f
orwarding ingress fei
_
1/1 11
egress fei_1/3 21
ZXR10(config)#vlan-
f
orwarding ingress fei
_
1/1 12
egress fei_1/3 22
ZXR10(config)#vlan-
f
orwarding ingress fei
_
1/1 13
egress fei_1/3 23
ZXR10(config)#vlan-
f
orwarding ingress fei
_
1/1 14
egress fei_1/3 24
ZXR10(config)#vlan-
f
orwarding ingress fei
_
1/1 15
egress fei_1/3 25
ZXR10(config)#vlan-
f
orwarding ingress fei
_
1/1 16
egress fei_1/3 26
ZXR10(config)#vlan-
f
orwarding ingress fei
_
1/1 17
egress fei_1/3 27
ZXR10(config)#vlan-
f
orwarding ingress fei
_
1/1 18
egress fei_1/3 28
ZXR10(config)#vlan-
f
orwarding ingress fei
_
1/1 19
egress fei_1/3 29
ZXR10(config)#interface fei_1/4
ZXR10(config-
i
f)#ip address 192.168.1.1
255.255.255.252
ZXR10(config)#interface fei_1/2.30
ZXR10(config-subif)#encapsulation dot1q 30
ZXR10(config-
s
ubif)#ip address 10.1.1.1
255.255.255.192
ZXR10(config)#interface fei_1/2.31
ZXR10(config-subif)#encapsulation dot1q 31
ZXR10(config-
s
ubif)#ip address 10.1.1.65
255.255.255.192
Note: Interface forwarding attributes cover: normal, mix and
vlan-switch. Normal: In this mode, packets are forwarded in the
mode of searching routes based on the normal IP address; mix:
In this mode, search the vlan-switch forwarding table first. If
there is a matched vlan-switch table, packets are forwarded in
the vlan-switch transparent transmission mode. Otherwise,
packets are forwarded by searching routes based on the normal
IP address; vlan-switch: In this mode, search the vlan-switch
forwarding table first. If there is a matched vlan-switch table,
packets are forwarded in the vlan-switch transparent
transmission mode. Otherwise, packets are discarded.
V_Switch Maintenance and
Diagnosis
Refer to below procedure for configuring V_switch maintenance
and diagnosis on ZTE ZXR10 GER router.
Router Command Line Interface has been accessed.
Purpose
Prerequisite
