ZXR10 GER (V2.6.03) General Excellent Router User Manual Volume-I
196 Confidential and Proprietary Information of ZTE CORPORATION
Configuration of R2:
ZXR10_R2(config)#interface fei_1/1
ZXR10_R2(config-if)#ip address 10.0.0.2 255.255.255.0
ZXR10_R2(config-if)#ip ospf authentication-key ZXR10
ZXR10_R2(config-if)#exit
ZXR10_R2(config)#interface fei_1/2
ZXR10_R2(config-if)#ip address 10.0.1.1 255.255.255.252
ZXR10_R2(config-if)#ip ospf message-digest-key 1 md5 ZXR10
ZXR10_R2(config-if)#exit
ZXR10_R2(config)#router ospf 1
ZXR10_R2(config-router)#network 10.0.0.0 0.0.0.255 area 0.0.0.0
ZXR10_R2(config-router)#network 10.0.1.0 0.0.0.3 area 0.0.0.1
ZXR10_R2(config-router)#area 0 authentication
ZXR10_R2(config-router)#area 1 authentication message-digest
Configuration of R3:
ZXR10_R3(config)#interface fei_1/1
ZXR10_R3(config-if)#ip address 10.0.1.2 255.255.255.252
ZXR10_R3(config-if)#ip ospf message-digest-key 1 md5 ZXR10
ZXR10_R3(config-if)#exit
ZXR10_R3(config)#interface fei_1/2
ZXR10_R3(config-if)#ip address 10.0.2.1 255.255.255.0
ZXR10_R3(config-if)#exit
ZXR10_R3(config)#router ospf 1
ZXR10_R3(config-router)#network 10.0.1.0 0.0.0.3 area 0.0.0.1
ZXR10_R3(config-router)#network 10.0.2.0 0.0.0.255 area 0.0.0.2
ZXR10_R3(config-router)#area 1 authentication message-digest
For additional information on OSPF additional configurations,
please refer to below procedures.
Configuring OSPF Area Parameters
and NSSA
This below procedure describes how to configure OSPF area
parameters and NSSA.
 Router Command Line Interface has been accessed.
 OSPF is running on a network as described in above basic
OSPF configuration.
Note: There are three types of areas configurations
f Stub area
Related
Information
Purpose
Prerequisites
